Intel Desktop Board D945GCCR Technical Product Specification
Resume on Ring enables telephony devices to access the computer when it is in a
power-managed state. The method used depends on the type of telephony device
(external or internal).
NOTE
The use of Resume on Ring and Wake from USB technologies from an ACPI state
requires an operating system that provides full ACPI support.
1.11.2.1

Power Connector

ATX12V-compliant power supplies can turn off the system power through system
control. When an ACPI-enabled system receives the correct command, the power
supply removes all non-standby voltages.
When resuming from an AC power failure, the computer returns to the power state it
was in before power was interrupted (on or off). The computer's response can be set
using the Last Power State feature in the BIOS Setup program's Boot menu.
For information about
The location of the main power connector
The signal names of the main power connector
1.11.2.2

Fan Headers

The function/operation of the fan headers is as follows:
• The fans are on when the board is in the S0 or S1 state.
• The fans are off when the board is off or in the S3, S4, or S5 state.
• Each fan header is wired to a fan tachometer input of the hardware monitoring and
fan control ASIC.
• All fan headers support closed-loop fan control that can adjust the fan speed or
switch the fan on or off as needed.
• All fan headers have a +12 V DC connection.
For information about
The location of the fan headers
The location of the fan headers and sensors for thermal monitoring
The signal names of the processor fan header
The signal names of the chassis fan headers
36
Refer to
Figure 13, page 50
Table 21, page 53
Refer to
Figure 13, page 50
Figure 9, page 32
Table 19, page 52
Table 20, page 52
