Board Components Shown In Figure 1 - Intel BLKD945GCCR Specification

Table 2. Board Components Shown in Figure 1
Item/callout
from Figure 1 Description
A Front panel audio header
PCI Conventional bus add-in card connector #2
B
C PCI Conventional bus add-in card connector #1
D PCI Express x1 bus add-in card connector
PCI Express x16 bus add-in card connector
E
F Back panel connectors
Processor core power connector
G
H Processor fan header
Rear chassis fan header
I
J LGA775 processor socket
Intel 82945GC GMCH
K
L DIMM socket
DIMM socket
M
N Chassis intrusion header
Main Power connector
O
P Diskette drive connector
Parallel ATE IDE connector
Q
R Intel 82801GB I/O Controller Hub (ICH7)
Front chassis fan header
S
T Serial ATA connectors [4]
Front panel header
U
Speaker
V
W Front panel USB headers [2]
BIOS Setup configuration jumper block
X
Y Battery
Auxiliary front panel power LED header
Z
Product Description
13
