Table 15 lists the component-side connectors and headers identified in Figure 13.
Table 15. Component-side Connectors and Headers Shown in Figure 13
Item/callout
from Figure 13
Description
A
Front panel audio header
PCI Conventional bus add-in card connector 2
B
C
PCI Conventional bus add-in card connector 1
PCI Express x1 bus add-in card connector
D
E
PCI Express x16 bus add-in card connector
Processor core power connector
F
G
Processor fan header
Rear chassis fan header
H
I
Chassis intrusion header
Main power connector
J
K
Diskette drive connector
Parallel ATA IDE connector
L
M
Front chassis fan header
N
Serial ATA connector 1
Serial ATA connector 3
O
P
Serial ATA connector 2
Front panel header
Q
R
Serial ATA connector 0
Front panel USB header
S
T
Front panel USB header
Auxiliary front panel power LED header
U
