Layout contents

Connectors/Jumpers/Slots
1. CPU,Chassis, and Power fan connectors (4-pin CPU_FAN, 4-pin
CHA_FAN, 3-pin PWR_FAN)
2. EATX power connectors (24-pin EATXPWR, 8-pin EATX12V)
3. GPU Boost switch
4. GPU Boost LED
5. Intel ® CPU socket
6. DDR3 DIMM sockets
7. MemOK! switch
8. DRAM LED
9. USB 3.0 connector (20-1 pin USB3_34)
10. Marvell ® Serial ATA 6.0 Gb/s connectors (7-pin SATA 6G_E1
[navy blue])
11. EPU switch
12. Intel ® H77 Serial ATA 6.0Gb/s connectors (7-pin SATA6G_1/2
[gray])
13. Intel ® H77 Serial ATA 3.0Gb/s connectors (7-pin SATA3G_1-4,
[Blue])
14. EPU LED
15. Onboard LED (SB_PWR)
16. System panel connector (20-8 pin F_PANEL)
17. Clear RTC RAM (3-pin CLRTC)
18. USB connectors (10-1 pin USB56, USB78, USB910)
19. Serial port connectors (10-1 pin COM1)
20. LPT connector (26-1 pin LPT )
21. Front panel audio connector (10-1 pin AAFP)
22. Digital audio connector (4-1 pin SPDIF_OUT)
ASUS P8H77-M PRO
Page
2-24
2-25
2-16
2-18
2-4
2-5
2-15
2-17
2-22
2-21
2-16
2-19
2-20
2-17
2-17
2-26
2-14
2-22
2-25
2-24
2-23
2-23
2-3
