SEWING MACHINE
Owner's Manual (Operating fundamentals)
MAQUINA DE COSER
Manual de lnstrucciones
MACHINE A COUDRE
Manuel d'instructions
Model, Modelo, Modele 385.19110
I
843-870-382
Sears,
Roebuck
and Co., Hoffman
Estates,
IL 60179
U.S.A.
Sears
Canada
inc.,
Toronto,
Ont.,
M5B 2B8 CANADA
www.sears.com
www.sears.ca
