Reference Manual for the ProSafe Wireless 802.11g Firewall/Print Server Model FWG114P v2
Figure H-11: NETGEAR FVS328 VPN Policies Menu (Post Configuration)
When the screen returns to the VPN Policies, make sure the Enable check box is selected.
6.
Click the Apply button.
Test the VPN Connection
From a PC behind the NETGEAR FVS318 or FVM318 Gateway A, attempt to ping the
1.
remote FWG114P v2 Gateway B LAN Interface address (example address 172.23.9.1).
2. From the FVS318 or FVM318, click the Router Status link on the left side of the Settings
management menu. Click the Show VPN Status button. This will take you to the IPSec
Connection Status Screen. If the connection is functioning properly, the State fields will show
"Estab."
3. From the FVS328, click the VPN Status link under the VPN section of the main menu. The
VPN Logs and status are displayed.
NETGEAR VPN Configuration FVS318 or FVM318 with FQDN to FVS328
201-10301-02, May 2005
H-11
