Icon

Selecting An Aspect Ratio Mode

The aspect ratio modes available for your selection depends on the current input source. Use the
following table to determine which mode is available for your monitor.
ARC \ Mode
16:9
Just Scan
Original
4:3
1:1
14:9
Zoom1
Zoom2
ENWW
Main Menu
Submenu
Option
Language
Key Lock
ISM Method
Power Indicator
DPM (Display
Power
Management)
Select
Tile Mode
Factory Reset
Information
Set ID
Serial No
SW Version
AV
Component
X
X
X
X
X
X
X
X
X
Description
Selects the language in which the OSD menu is displayed.
Sets up the monitor so that it can only be used with the remote
control. This feature can prevent unauthorized viewing.
Avoids allowing a fixed or burn-in image to remain on the screen
for a long period of time.
Sets the power indicator on the front of the monitor to On or Off.
Turns the power saving mode on or off.
Enlarges the screen and is also used with several products to
view the screen. To use this function, it:
must be displayed with several other products.
must be in a function that can be connected to RS232C or
RGB Out.
Select this option to return to the default factory settings.
Assigns a unique Set ID number (name assignment) to each
product when several products are connected for display.
Specify the number (1 ~ 99) using the up and down buttons and
exit. Use the assigned Set ID to individually control each product
using the Product Control Program.
Displays the serial numbers of the product.
Displays the software version.
HDMI/DVI
RGB
DTV
PC
PC
X
X
X
X
X
X
X
X
X
Using the On-Screen Display Menu
27
