- Page 1 DIAL CODE CONTROLLER Telephone Entry System with 32 Zone control with BUILT-IN surge suppression...
-
Page 2: Table Of Contents
Dial Code Controller Features (Processor) ........ -
Page 3: Dial Code Controller Overview
DIAL CODE CONTROLLER OVERVIEW STANDARD FEATURES • Two line Large LC Display. • Memory capacity: 250, 500, 1000 names. • User-friendly programmability via built-in alpha-numeric keyboard eliminates the need for user's manual. • Four character alpha-numeric password required to enter •... -
Page 4: Dial Code Controller Features (Inside)
DIAL CODE CONTROLLER FEATURES (INSIDE) Memory Card Memory Memory Processor Card Slot Card Release Power Switch Buttons Mounting Holes (4) Processor Key Release / Lock LC Display Stainless Processor Unit Steel Door Key Lock Dialing Keys Programming Keys Parallel Port... -
Page 5: Dial Code Controller Features (Outside)
DIAL CODE CONTROLLER FEATURES (OUTSIDE) 16 GAUGE STAINLESS STEEL DOOR - Heavy-duty and weather resistant. KEY LOCK - Opens the Processor Containment Box to access the Processor. PROCESSOR CONTAINMENT BOX - 16 Gauge Stainless Steel Powder Coated. All components and specifications are subject to change without notice. -
Page 6: Dial Code Controller Features (Processor)
DIAL CODE CONTROLLER FEATURES (PROCESSOR) MEMORY CARD - STORES ALL PROGRAMMED INFOR- MATION. (DIFFERENT MEMORY SIZES AVAILABLE) COMMUNICATOR CARD - CARD FOR RS-485 DEVICES. Remote Access RS-485 COMMUNICATOR CARD POWER ON/OFF SWITCH capacity CARD RELEASE BUTTONS - EJECT CARDS WHEN Elite Entry Phone PRESSED. -
Page 7: Mounting Specifications
MOUNTING SPECIFICATIONS " Mounting Holes (4) Wall 1" Installation on Wall " Remove the Processor Unit from 8 " Wire Knock Outs Processor Containment bolt Processor Containment Box to the recess in the " wall using the four mounting holes. Feed the power and phone Knock lines... -
Page 8: Description Of Surge Suppression Terminal Board
DESCRIPTION OF SURGE SUPPRESSION TERMINAL BOARD POWER Knockouts for AC/DC LINE RING INPUT Incoming Wires RS-485 (1) DOOR-NO DOOR DOOR-NC RELAY DOOR-C RS-485 (2) GATE-NO GATE GATE-NC RELAY Removable Screw Terminal Connectors for Easy Wiring. GATE-C RS-485 (3) VCR-NO RELAY VCR-C TELEPHONE LINE: Tip and Ring Connection. -
Page 9: Grounding The Unit
GROUNDING THE UNIT Chassis Ground It is MANDATORY that this unit is properly grounded. The provided "chassis ground" wire must be connected to the ground rod. If unit is not grounded, lightning damage will occur. Please refer to the owners manual for proper grounding instructions. -
Page 10: Earth Ground Rod Installation
EARTH GROUND ROD INSTALLATION Proper grounding gives an electrical charge, such as from an electrical static discharge or a near lightning strike, a path from which to dissipate its energy safely into the earth. Without this path, the intense energy generated by lightning could be directed towards the Elite Entry Phone System. Although nothing can absorb the tremendous power of a direct lightning strike, proper grounding can protect the Entry Phone System in most cases. -
Page 11: Basic Wiring Diagram
BASIC WIRING DIAGRAM Telephone Line: MUST be a dedicated line for the phone system ONLY! NOTE: Installation where fiber optic cables are present may require additional modifications from your telephone provider. Contact your provider for more Use 18 AWG wire where possible information. -
Page 12: Rs-485 Multiple Connections Configuration
RS-485 MULTIPLE CONNECTION CONFIGURATIONS “Daisy Chain” Configuration #1 wiring configuration (Recommended method for superior data transmission) • Up to 31 RS-485 devices supported • Maximum distance from the last RS-485 device to the Entry Phone is 4000 Ft. • Turn “ON” the terminator switch ONLY for the last device installed in the RS-485 line. •... -
Page 13: Rs-485 Daisy Chain Connection Example
RS-485 DAISY CHAIN CONNECTION EXAMPLE “Preferred Method” Remote Access RS-485 COMMUNICATOR CARD POWER capacity LINE RING AC/DC INPUT RS485 (1) Elite Entry Phone DOOR-NO DOOR DOOR-NC RELAY DOOR-C RS485 (2) GATE-NO GATE GATE-NC RELAY RS485 Card Release Button GATE-C RS485 (3) VCR-NO RELAY VCR-C... -
Page 14: Rs-485 Star Connection Example
RS-485 STAR CONNECTION EXAMPLE Keypad RS485 Remote Use 22 AWG Twisted Pair Shielded Wire Remote Access RS-485 Device 1 COMMUNICATOR CARD capacity Ground Elite Entry Phone RS485 Card Release Button Stand-Alone Receiver RS485 Remote Device 2 NOTE: To support RS485 devices you must insert the RF communicator card in the RS485 memory card slot BEFORE turning on the processor. -
Page 15: Memory Card Installation
Code systems for easy reference. Turn power off and insert memory card in main memory card slot. Turn power on and the information screen should display as seen in (fig e.) MEMORY CAPACITY DIAL CODE LC-250 REV. 1.00_ (fig e.) SOFTWARE VERSION NUMBER... -
Page 16: Warnings And Precautions
WARNINGS AND PRECAUTIONS Do not touch the terminals on the RAM Cards. Do not bend, drop or expose to impact. The Entry Phone is only water resistant when the Stainless Steel Door is closed and locked. Do not expose the Processor Unit or the open Processor Containment Box to rain, snow, or harsh weather conditions. -
Page 17: Programming The Processor
PROGRAMMING THE PROCESSOR ENTERING THE PROGRAM MODE When the Processor unit is turned on and the button is pressed, the screen will display: TO ENTER PROG MODE, Type Password >____ Type in the factory present password (7777). Press . The Program Selection Screen will display: SELECT PROG MODE: (N)Names (U)Utility... -
Page 18: Selecting A Program Mode
SELECTING A PROGRAM MODE LIST OF PROGRAM MODES: Program Names or Transmitter/Card Reader Page 18-19 Names Program or edit Utility Codes Utility Page 20 Program New Password ( recommended ) Password* Page 21 Program System Clock and Seven Day Timers Clock/Timer Page 22-24 Program relay Output Time ( for 2 relays ) -
Page 19: Resident Information
RESIDENT INFORMATION In the Program Selection Screen (fig a.), Press the key. The screen will display (fig b.): STEP SELECT PROG MODE: PROG A NEW NAME (N)Names (U)Utility PROG BY CODE:___ (fig a.) (fig b.) STEP You now have three options: To program by name, press To program by code, enter To view or edit an existing name... -
Page 20: Transmitter/Card Reader Programming
TRANSMITTER/CARD READER PROGRAMMING STEP To complete entry, press the key to return to the program selection screen. To program RF devices ( i.e. transmitters/cards etc.) continue on to Step 7. NOTE: To enable the transmitter/card programming feature, you must insert the communicator card in the “RS-485 memory card slot”... -
Page 21: Utility Codes
UTILITY CODES A 4-digit Utility Code (numeric characters only) may be assigned to “Utility Companies” such as delivery, telephone, construction companies, water, power, etc. These utilities can use their individual code to access the premises within the time zone that you program. Each system, no matter what the memory capacity, is equipped with 60 available Utility Codes and time zones. -
Page 22: Changing The Password
CHANGING THE PASSWORD The factory default password is 7777. We suggest that you customize it for security purposes. In the Program Selection Screen (fig a.), press the SELECT PROG MODE: key. (P)Password (fig a.) To customize a password, type in a four character password (it may be alpha or numeric characters). -
Page 23: Clock/Timer
CLOCK/TIMER The Clock/Timer allows you to set the date and time, and to program gates and doors to be opened or closed when- ever specified. This clock is equipped with a calender, auto leap year compensation and daylight savings. In the Program Selection Screen (fig a.), Press the SELECT PROG MODE: key. - Page 24 CLOCK/TIMER CONTINUED 2./ 3. DOOR AND GATE TIMERS Press to program Gate Timers Menu. Press to program the Door Timers Menu. Setup New Timers> N See next page for instructions View/Edit Timers> to View / Program Individual Time Zones SUN G Tmr1: OFF N=on to view and program timer(s) for 12:00am ->...
- Page 25 CLOCK/TIMER CONTINUED 2./ 3. DOOR AND GATE TIMERS, continued’ Press to program Gate Timer Menu Press to program the Door Timers Menu Press to Program Setup New Timers> N sets of time zones View/Edit Timers> See previous page for instructions Program timers 1 &...
-
Page 26: Strike Time
STRIKE TIME Strike Time sets the amount of time your gate or door relay will be held open. In the Program Selection Screen (fig a.), Press the SELECT PROG MODE: key. (S)Strike Time (fig a.) The strike time can be individually set for both Door Strike Time >... -
Page 27: Error Messages
(fig e.) *IMPORTANT NOTE: In order to charge the battery in the Dial Code System, the processor must be plugged in to the transformer and the processor MUST BE ON. If the power is off on the processor, the battery will not be charging. -
Page 28: Parts List And Part Illustrations
T000 Transformer 12 VAC 50VA (Provided) T036 Heater Pad Option (Pre-Installed in Processor) T003 Keylock T060 Dial Code Surge Protection Board T009 Processor Containment Box (Back Box) T100 16.5 VAC 50 VA Transformer (Optional) T010 Processor Key Release / Lock... -
Page 29: Approvals
APPROVALS The Chamberlain Group Inc. Complies with Part 68, FCC Rules FCC Part 15 - Tested to comply with UL STD 294, 5th Ed. FCC standards for home or office use UL STD 1950, 3rd Ed. This Class B digital apparatus meets all requirements of CANADIAN Interference Causing Equipment Regulations. - Page 30 845 Larch Avenue © 2008 The Chamberlain Group, Inc. – All Rights Reserved Elmhurst, Illinois 60126-1196 114A2867C...
