Chamberlain Dial Code Installation Manual

Dial Code
Flush Mount Installation
Flush
Mount
Assembly
Recess Box
Dial Code LC or Dial Code VF
Flush Mount
Recess Box Flush Mount
SIDE
SIDE FRONT
FRONT
1.315 X1.0625
0
(4 PLCS)
17"
16.68" 19"
9.5 "
5.69"
4.53" 11.75"
BOTTOM
13.75"
3.31"
BOTTOM
C L
11.5"
®
845 Larch Ave., Elmhurst, IL 60126-1196
www.chamberlain.com
© 2006, The Chamberlain Group, Inc. • All Rights Reserved 114A2930B
