Preliminary Installation Information
Subject
200 Pound Tumble Dryer
Use With 70420801 Installation Manual
Model Identification
DR200G2-BA200L
DR200G2-BA200N
DR200G2-BT200L
DR200G2-BT200N
DR200G2-BU200L
DR200G2-BU200N
200 Pound
CA200L
CA200N
CT200L
CT200N
CU200L
CU200N
HA200L
Includes models with the following control suffixes:
R3 – reversing DX4 OPL
RD – reversing DMP OPL
Gas
HA200N
HT200L
HT200N
HU200L
HU200N
IT200L
IT200N
SA200L
SA200N
ST200L
ST200N
SU200L
SU200N
RE – reversing OPL Micro
RM – reversing OPL Micro
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
UA200L
DR200S2-BT200S
UA200N
DR200S2-BT200T
UT200L
DR200S2-BU200S
UT200N
DR200S2-BU200T
UU200L
CT200S
UU200N
CT200T
CU200S
CU200T
HT200S
Page 1 of 12
Steam/Thermal Oil
HT200T
HU200S
HU200T
IT200S
IT200T
ST200S
ST200T
SU200S
SU200T
UT200S
UT200T
UU200S
UU200T
RQ – reversing dual digital timer
RU – reversing UniLinc OPL
Part No. 70470101R1
April 2012
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Alliance Laundry Systems 70420801
Summary of Contents for Alliance Laundry Systems 70420801
-
Page 1: Model Identification
CT200N CU200L CU200N HA200L Includes models with the following control suffixes: R3 – reversing DX4 OPL RD – reversing DMP OPL © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT HA200N UA200L HT200L UA200N HT200N UT200L HU200L... -
Page 2: Specifications And Dimensions
Steam Coil Rating at 100 psig:Boiler Horsepower (Btu/hr.) (recommended operating pressure 80-100 psig) Heating Element Rating:Kilowatts (kW) N/A = Not Applicable © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Gas Models Steam Models Electric Models Page 2 of 12... - Page 3 Refer to Position and Level the Tumble Dryer to temporarily reduce the heights of these models. Models 67.19 in. 200L/N/S (1707 mm) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT TOP VIEW OF EXHAUST DUCT Cabinet Dimensions 58 in.
-
Page 4: Electric And Gas Connection Locations For Gas Models
81 in. 13.7 in. 77.4 in. 1 in. NPT 200L/N (533 mm) (2057 mm) (348 mm) (1966 mm) NOTE: These figures are approximate dimensions only. Page 4 of 12 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 5: Electric And Steam Connection Locations For Steam Models
Models Diameter 1 in. NPT 200S Models 21 in. 200S (533 mm) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Steam Inlet 37.625 in. (956 mm) Steam Outlet 44.625 in. (1133 mm) Electrical Connection 81 in. -
Page 6: Position And Level The Tumble Dryer
Make-Up Air Required Make-Up Air Opening (to the outside) for Each Tumble Dryer Models Opening 525 in. (3710 cm 200 Pound free air Table 1 Page 6 of 12 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT... -
Page 7: Exhaust Requirements
NOTE: Where the exhaust duct pierces a combustible wall or ceiling, the opening MUST be sized per local codes. Duct Stations © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT ONE MANIFOLD ASSEMBLY Figure 1 12 in. (305 mm) Duct Table 2... - Page 8 NOTE: Where the exhaust duct pierces a combustible wall or ceiling, the opening MUST be sized per local codes. Duct Stations © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT TWO MANIFOLD ASSEMBLIES Outlet Duct Diameter 45° Typical Figure 2 200 Pound 12 in.
-
Page 9: Gas Requirements
4001 – 6000 L.P. 6001 – 8000 8001 – 10,000 * Btu/hr. derate of 4% per 1000 ft. (305 m) of altitude. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Non-CE Models inches 610 – 1220 .1660 1221 –... -
Page 10: Electrical Requirements
440V/60Hz/3ph L1, L2, L3 and ground 460-480V/60Hz/3ph * Current ratings vary slightly depending on model; refer to serial plate. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT For 200 Pound Tumble Dryer Models Terminal Block Rated... -
Page 11: Steam Requirements
Condensate Return Line from Supply Line Steam Pressure Model 80-100 (5.3-6.9) 200S * Based on maximum psi. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Figure 3 Minimum PSI (bar) Supply Pipe Diameter 1-1/4 in. NPT... -
Page 12: Loading Door Strike
Door Strike Adjustment Screws Figure 4 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Belt Drive NOTE: Proper tensions for new belts are 45-55 pounds for the motor belt, 55-65 pounds for the final drive and 65-70 pounds for 200 pound blower, measured with a Borroughs Belt Tension Gauge.
