Dual digital control tumble dryer
Hide thumbs Also See for BA025E:
Table of Contents

Advertisement

Quick Links

Tumble Dryer
Dual Digital Control
Refer to Page 7 for Model Numbers
Original Instructions
Keep These Instructions for Future Reference.
CAUTION: Read the instructions before using the machine.
(If this machine changes ownership, this manual must accompany machine.)
Part No. 70579901ENR9
www.alliancelaundry.com
October 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BA025E and is the answer not in the manual?

Questions and answers

Related Manuals for Alliance Laundry Systems BA025E

Summary of Contents for Alliance Laundry Systems BA025E

  • Page 1 Tumble Dryer Dual Digital Control Refer to Page 7 for Model Numbers Original Instructions Keep These Instructions for Future Reference. CAUTION: Read the instructions before using the machine. (If this machine changes ownership, this manual must accompany machine.) Part No. 70579901ENR9 www.alliancelaundry.com October 2022...
  • Page 3 These conditions will obstruct tumble dryer W052 airflow and increase the risk of fire. W752R1 The following information applies to the state of Massachusetts, USA. © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 4 A “T-Handle” type gas shut-off valve must be installed in the gas supply line to this appliance. • This appliance must not be installed in a bedroom or bath- room. © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...

  • Page 5: Table Of Contents

    Stand Alone Tumble Dryer................28 © Copyright 2022, Alliance Laundry Systems LLC All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher.
  • Page 6 Damper Motor Test d 39 (steam models only)..........47 Drive Motor Test d 40 ................47 Factory Test Cycle................48 Factory Test Quick Reference Chart..............48 Error Codes ..................50 © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...

  • Page 7: Introduction

    GU025L HL025L NA025N PH025E SH025F UA025L UT025L BK025E GU025N HR025E NA025S PH025L SH025L UA025N UT025N BK025F GU025S HR025S NG025E PH025N SH025N UA025R UT025R Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 8 GH030E HJ030L MJ030D PA030L SG030E SU030F UL030E BJ030E GH030L HJ030N MJ030E PA030N SG030F SU030L UL030L BJ030F GH030N HJ030R MJ030F PA030S SG030L SU030N UR030E Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 9 GAT30L HHT30L MGT30D NTT30N SAT30E STT30E UJT30R BHT30E GAT30N HHT30N MGT30E NTT30S SAT30F STT30F UJT30S BHT30F GAT30S HHT30R MGT30F NUT30E SAT30L STT30L UKT30E Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 10 BU035F HG035F HU035N NJ035N PT035E SK035E UH035L BA035S BU035L HG035L HU035R NJ035S PT035L SK035F UH035M BG035D BU035M HG035M HU035S NK035E PT035M SK035L UH035N Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 11 GU035N HT035F NG035N PJ035E SH035R UG035D UU035L BR035S GU035S HT035L NG035S PJ035L SH035S UG035E UU035M BT035D HA035E HT035M NH035E PJ035M SJ035D UG035F UU035N Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 12 GA050S HH050E MG050D NK050N PK050L SJ050L UH050E BG050D GG050E HH050L MG050E NR050E PK050N SJ050N UH050L BG050E GG050L HH050N MG050L NR050S PR050E SJ050S UH050N Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 13 BT055R HG055E HU055F NK055L PU055L SL055L UJ055D BA055S BU055E HG055F HU055L NK055N PU055N SL055S UJ055E BG055D BU055F HG055L HU055N NR055E PU055R SR055E UJ055F Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 14 BT055D HA055L HT055L 75 Pound (34 Kg) BA075E BT075N HA075N HU075E NH075N PJ075S SJ075F UG075N BA075F BT075R HA075R HU075F NH075S PK075E SJ075L UG075R Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 15 GK075L HR075E NA075N PG075S SG075S UA075L UT075N BK075L GK075N HR075S NA075S PH075E SH075E UA075M UT075R BK075N GU075E HT075C NG075E PH075L SH075F UA075N UT075S Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 16 GK120E HR120E NH120S PH120E SG120E SU120S UT120N BR120S GK120L HR120S NJ120E PH120L SG120L UA120E UT120S BT120E GK120N HT120C NJ120L PH120N SG120N UA120L UU120E Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 17 GA200L HA200S HU200S NT200L PK200N SJ200N UH200L BG200L GA200N HG200L KT200L NT200N PR200S SJ200S UH200N BG200N GA200S HG200N KT200N NT200S PT200C SK200L UH200S Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 18 D - Liquid Petroleum (L.P.) Gas, Japan E - Electric F - Reduced Electric (Eco Line) L - L.P. Gas M - Medium Electric Table continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 19 N - OPL FN- Dual Digital Control, OPL Design Digit (Position 13) Tumble Dryer - 3, 5 and 6 Stacked Washer-Extractor/Tumble Dryer - 1 and 2 © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...

  • Page 20: Preliminary Information

    START pad. If the power failure occurs while the control is in a fatal error mode, it will return to Start Mode upon recovery. © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...

  • Page 21: Control Identification

    2. 7-segment Digits 3. Increase/Decrease COOL DOWN TIME 4. START (enter) Keypad 5. REVERSING Keypad 6. DISPLAY Keypad 7. SELECT Temperature Keypad 8. Increase/Decrease HEAT TIME © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 22 5. REVERSING Keypad 6. DISPLAY Keypad 6. DISPLAY Keypad 7. SELECT Temperature Keypad 7. SELECT Temperature Keypad 8. Increase/Decrease HEAT TIME 8. Increase/Decrease HEAT TIME © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 23 2. 7-segment Digits 3. Increase/Decrease COOL DOWN TIME 4. START (enter) Keypad 5. REVERSING Keypad 6. DISPLAY Keypad 7. SELECT Temperature Keypad 8. Increase/Decrease HEAT TIME © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...

  • Page 24: Display Identification

    During diagnostic testing, these digits will display descriptive codes and values (as described in How to Enter Manual Programming Mode). © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...

  • Page 25: Special Features

    Mode. At this point, the owner can perform the required tests and then return the machine to the point it was interrupted. For information on using the Rapid Advance feature, refer to Run Mode. © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...

  • Page 26: Machine Operation

    If the Rapid Advance Feature is enabled, press the START (enter) keypad to decrement one minute per key press. Once the cycle is complete, the control will proceed to the End of Cycle Mode. © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 27 By disabling this feature, you hereby re- lease and hold harmless Alliance Laundry Systems LLC of any damages caused by fire, including but not limited to, property damage, personal injury or...

  • Page 28: Opening The Service Door

    "white/black" and "red/blue" wires for one second, Stand Alone Tumble Dryer then reconnect. Refer to Figure 1 . Unlock access panel over control and remove. Figure 1 © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 29 Opening the Service Door TMB1790R_SVG TMB1791R_SVG 1. Control Figure 2 © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...

  • Page 30: Entering The Manual Mode

    Simultaneously press the SELECT (∧) and DISPLAY (∨) key- pads until the control returns to the mode that was active before Manual Mode was entered. © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...

  • Page 31: Rapid Advance Feature

    START (enter) keypad to exit the rapid ad- vance option. 5. Simultaneously press the SELECT (∧) and DISPLAY (∨) key- pads to return to the Manual Mode menu. © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...

  • Page 32: Collecting Audit Information

    Display Description Total number of cycles Cy C Total number of run hours ru hr Total number of rapid advance rA Pd cycles Table 2 © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...

  • Page 33: Machine Diagnostic Functions

    30 bX XX Machine Configuration #3 Display Test d 31 CX XX Machine Configuration #4 Display Test d 32 dX XX Table 3  continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...

  • Page 34: Diagnostic Test Descriptions

    PLAY (∨) keypads. The control will return to the Manual Diag- number. To start test, control must be in the Manual Diagnostic nostic Mode Menu. Mode Menu. © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...

  • Page 35: Service Door Switch Input Test D 08

    This test will display whether the lint door switch is open or PLAY (∨) keypads. closed. To start test, control must be in the Manual Diagnostic Mode Menu. © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...

  • Page 36: Machine Configuration #1 Display Test D 29

    T30 Pound Stack Tumble Dry- er and S30 Stacked Washer- Extractor/Tumble Dryer Table 5  continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 37 Machine Diagnostic Functions Table 6  continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 38 Machine Diagnostic Functions Table 6  continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 39 Machine Diagnostic Functions Table 6  continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 40 Machine Diagnostic Functions Table 6  continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 41 Machine Diagnostic Functions Table 6  continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 42 Machine Diagnostic Functions Table 6  continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 43 Machine Diagnostic Functions Table 6  continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 44 Machine Diagnostic Functions Table 6  continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 45 Machine Diagnostic Functions Table 6  continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...

  • Page 46: Machine Configuration #5 Display Test D 33

    To exit the test, simultaneously press the SELECT (∧) and DIS- Low kW Electric PLAY (∨) keypads. The control will return to the Manual Diag- nostic Mode Menu. Table 7  continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...

  • Page 47: Heat Interlock Test D 36

    FA n to indicate the fan motor is going to run. NOTE: This test does not count towards the total ma- chine run time operation. © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...

  • Page 48: Factory Test Cycle

    When all key- pads have been pressed, the control will advance to Show Entire Display Mode test cycle. Table 8  continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 49 Table 8 NOTE: If power to the control is turned off before 10 Mi- nute Test Cycle has ended, the cycle will be cleared from control. © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...

  • Page 50: Error Codes

    Hardware failure. Replace output board. E nr Open Thermistor Error Remove any lint build-up around thermis- E oP tor. If problem persists, replace control or thermistor. Table 9  continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 51 Dryer Designs 1 and 2) the reversing pause time if reversing is en- abled. Error can be cleared by any key press. Table 9  continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 52 Power Fail Dangerous Error Check voltage to machine and voltage to EF 14, Ed 14 (Tumble Dryer Design 6) inverter drive. Table 9  continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 53 Check gas valve 1, if error persists replace EF t6 valve. Gas Valve 2 Output Shorted Error Check gas valve 2, if error persists replace EF t7 valve. Table 9  continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 54 Be sure to clean and inspect lint screen. Remove any lint buildup around the thermostat. If prob- lem persists, replace thermostat. Table 9  continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
  • Page 55 Be sure to clean and inspect lint screen. Remove any lint buildup around the thermostat. If prob- lem persists, replace thermostat. Table 9 © Copyright, Alliance Laundry Systems LLC - Part No. 70579901ENR9 DO NOT COPY or TRANSMIT...
