Tumble Dryers
Huebsch
18 Digit Model Numbers with 6 in 13th Position
Refer to Page 9 for Model Identification
Original Instructions
Keep These Instructions for Future Reference.
CAUTION: Read the instructions before using the machine.
(If this machine changes ownership, this manual must accompany machine.)
Part No. 70693401ENR6
www.alliancelaundry.com
January 2025
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Alliance Laundry Systems Huebsch 030 Series
Summary of Contents for Alliance Laundry Systems Huebsch 030 Series
- Page 1 Tumble Dryers Huebsch 18 Digit Model Numbers with 6 in 13th Position Refer to Page 9 for Model Identification Original Instructions Keep These Instructions for Future Reference. CAUTION: Read the instructions before using the machine. (If this machine changes ownership, this manual must accompany machine.) Part No.
- Page 3 IMPORTANT: The tumble dryer is not to be used if in- dustrial chemicals have been used for cleaning. Units are IPx4 when enclosed per these instructions. © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT...
- Page 4 • DO NOT let children play on or in the dryer. WARNING W931 To reduce the risk of serious injury: Avoid contact with hot surfaces. W927 © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT...
- Page 5 • A “T-Handle” type gas shut-off valve must be installed in the gas supply line to this appliance. • This appliance must not be installed in a bedroom or bath- room. © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT...
-
Page 6: Safety Information Safety Information
© Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT... -
Page 7: Explanation Of Safety Instruction Messages
Common sense, caution and care must be ex- stallation, operation, maintenance or servicing infor- ercised when installing, maintaining, or operating the mation that is important but not hazard related. tumble dryer. © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT... -
Page 8: Table Of Contents
Disposal of Unit ..................................................29 29 © Copyright 2024, Alliance Laundry Systems LLC All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. -
Page 9: Introduction
HU035M HA035L HG035E HH035E HJ035E HK035L HT035D HT035N HU035N HA035M HG035L HH035M HJ035M HK035N HT035E HU035E HU035R HA035N HG035M HH035N HJ035N HL035E HT035L HU035F continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT... - Page 10 HJ075F HK075E HT075D HT075R HU075N HA075N HG075M HH075M HJ075L HK075F HT075E HT075S HU075R HA075R HG075N HH075N HJ075M HK075L HT075F HU075E HU075S HA075S HG075R HH075R continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT...
- Page 11 F - Reduced Electric (Eco Line) L - L.P. Gas M - Medium Electric N - Natural Gas R - Reduced Gas, Natural Gas (Eco Line) S - Steam continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT...
-
Page 12: Contact Information
If you are unable to lo- cate an authorized service center, navigate to https://alliance- WARNING laundry.com/contact/ for the nearest Alliance Laundry Systems office for assistance. To reduce the risk of serious injury or death, DO... - Page 13 Introduction 30, T30, 35, T45, 55 Series TMB2721N_SVG 50, 75 Series TMB2707N_SVG 120, 170, 200 Series 170/200 TMB2734N_SVG 1. Serial Plate Figure 1 © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT...
-
Page 14: Operating Instructions Operating Instructions
START pad or button. NOTE: Activation of the emergency stop button stops all machine control circuit functions, but DOES NOT remove all electrical power from ma- chine. © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT... -
Page 15: Operating Instructions
When the cycle is complete, open door and remove the fire hazard. laundry. IMPORTANT: Load must go through a washer ex- traction cycle to remove excess moisture to avoid damage to tumble dryer. © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT... -
Page 16: Reversing Operation
5. Press the REVERSING keypad to change the cylinder rota- tion setting, if applicable. 6. Press the START keypad to start tumble dryer. Display will show minutes remaining before end of cycle. © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT... -
Page 17: Galaxy 600 (Vend)
4. When the cycle is complete, open door and remove the laun- dry. WARNING To prevent the risk of fire, remove laundry imme- diately in case of power failure. W779 © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT... -
Page 18: Galaxy (Opl)
After an hour, the machine enters extended tum- ble and will tumble for two minutes every hour for up to 18 hours or until the door is opened. © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT... -
Page 19: Ignition Control Operation And Troubleshooting
1. 12 VDC present between 12VDC and ground. If not, see ma- chine schematic. 2. 24 VDC present between TH and ground. If not, see machine schematic. continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT... -
Page 20: Proper Electrode Location
1.0 VDC, so a reading of 2.6 VDC would equate to 2.6 micro-amps. Figure 7 A good burner ground that matches the control ground is criti- cal for reliable flame sensing. © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT... -
Page 21: Maintenance Maintenance
A lazy yellow tipped flame indicates a lack of air. 3. Remove lint filter and thoroughly vacuum exhaust duct. b. A harsh, roaring, very blue flame indicates too much air. © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT... -
Page 22: Procapture Maintenance
NOTE: Loading door should be closed before clean- ing out lint. NOTE: For additional information on programmable options, refer to appropriate programming manual. Figure 11 © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT... - Page 23 NOTE: After cleaning out lint, if sensor still indicates lint accumulation, make sure sensor inside debris cleanout trap is clear of lint. © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT...
-
Page 24: Fire Suppression System (Optional Equipment) Maintenance Test
• DO NOT disconnect electric power to the dryer. • DO NOT disconnect water to the dryer. • DO NOT touch the dryer. Figure 17 W932 3. Remove lint from lint drawer. © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT... - Page 25 Table 1 , the fire suppression system has failed the maintenance test. Refer to the Troubleshooting Manual. IMPORTANT: If the fire suppression system failed the maintenance test, DO NOT operate the tumble dryer. © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT...
- Page 26 1. Spray Manifold 100 [45] 115-119 110 [50] 2. Water Spray [52-54] continues... Figure 20 Table 1 9. Clean up any water on the floor. © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT...
-
Page 27: Before You Call For Service Before Y Ou Call For Service
• Exhaust duct to outside is blocked. Clean out. • ProCapture models - lint compartment full. Clean lint compartment and clear prompt on control. continues... © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT... -
Page 28: Removing T Removing Tumble Dryer From Service Umble Dryer From Service
3. Turn off manual gas shut-off valve on machine. 4. Turn off steam supply external to machine. 5. Remove all electric, gas and steam connections. © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT... -
Page 29: Disposal Of Unit Disposal Of Unit
Figure 21 tact the local city office, household waste disposal service, or the source from which the product was purchased. © Copyright, Alliance Laundry Systems LLC - Part No. 70693401ENR6 DO NOT COPY or TRANSMIT...
