Alliance Laundry Systems 120 Series Installation & Operation Manual
  1. Manuals
  2. Brands
  3. Alliance Laundry Systems Manuals
  4. Dryer
  5. 120
  6. Installation & operation manual
Alliance Laundry Systems 120 Series Installation & Operation Manual

Alliance Laundry Systems 120 Series Installation & Operation Manual

Tumble dryers 120 pound (54 kilogram) capacity, 170 pound (77 kilogram) capacity, 200 pound (91 kilogram) capacity
Hide thumbs Also See for 120 Series:
Table of Contents

Advertisement

Quick Links

See also: Troubleshooting Manual
Original Instructions
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
Tumble Dryers
120 Pound (54 Kilogram) Capacity
170 Pound (77 Kilogram) Capacity
200 Pound (91 Kilogram) Capacity
Starting Serial No. 0907003062
Refer to Page 8 for Model Identification
www.alliancelaundry.com
TMB1268C_SVG
Part No. 70458101ENR9
September 2014
