Tumble Dryer Dual Digital Control Refer to Page 7 for Model Numbers Original Instructions Keep These Instructions for Future Reference. CAUTION: Read the instructions before using the machine. (If this machine changes ownership, this manual must accompany machine.) Part No. 70579901ENR12 January 2025...
Page 3
This specific regulatory information for tumble dryer installa- IMPORTANT: The installer must fully test the tumble tion and operation must be followed. dryer after installation and demonstrate to the owner how to operate the machine. Installation must conform with local codes or, in the absence of local codes, with: CAUTION In the U.S.A., installation must conform to the latest edition of...
Table of Contents Introduction Introduction......................................................6 6 Model Identification..........................6 Preliminary Information Preliminary Information............................................21 21 About the Control..........................21 Glossary of Terms ..........................21 Power Fail Recovery ..........................21 Control Identification Control Identification..............................................22 22 Select Cycle Keypads..........................22 Display Identification Display Identification..............................................25 25 Light Emitting Diodes (LEDs)......................25 CYCLE LED............................25 REVERSING LED (reversing models only) ..................25...
Page 5
Entering the Manual Mode Entering the Manual Mode ..........................................29 29 How to Enter the Manual Mode......................29 How to Exit Manual Mode........................29 Rapid Advance Feature Rapid Advance Feature..............................................30 30 Manual Rapid Advance Menu ......................30 Collecting Audit Information Collecting Audit Information..........................................31 31 Manual Read Audit Mode Menu......................31 Machine Diagnostic Functions...
Introduction Model Identification Information in this manual is applicable to these models. Refer to the machine serial plate for the model number Refer to the machine serial plate for the model number. . 025 Series (11 Kg) BA025E BU025F HG025E...
Page 14
Introduction 055 Series (24 Kg) * Only available in gas and electric BA055F BT055F HA055F HT055F NH055N PT055N SK055N UH055L BA055L BT055L HA055L HT055L NJ055E PT055S SK055R UH055N BA055N BT055N HA055N HT055N NJ055L PU055E SL055E UH055R BA055R BT055R HA055R HT055R NJ055N PU055F SL055L...
Page 15
Introduction 055 Series (24 Kg) * Only available in gas and electric BR055E GU055L HR055E NG055L PR055E SJ055S UG055R UU055R BR055S GU055N HR055S NG055N PR055S SK055E UH055E UU055S BT055D GU055S HT055D NH055E PT055E SK055F continues... 075 Series (34 Kg) BA075E BT075N GU075S HT075L...
Page 18
Introduction 170 Series (77 Kg) *Only available in gas and steam BK170L GJ170S HJ170N NG170N PA170S PU170S ST170S UT170C BK170N GK170L HJ170S NG170S PG170L SA170L SU170L UT170L BR170S GK170N HK170L NH170L PG170N SA170N SU170N UT170N BT170L GT170L HK170N NH170N PG170S SA170S SU170S UT170S...
Page 19
Introduction 030 (13/13 Kg) Stacked Washer-Extractor/Tumble Dryer * Only available in gas and electric HSA030N HSK030L SS030E-A SS030N-A SSG030L SSK030L SST030L UST030E HSG030E HSK030N SS030F-A SSA030N SSG030N SSK030N SST030N UST030N HSG030N HST030N SS030L-A SSG030E SSJ030D SST030E continues... 050 (22/22 Kg) Stacked Washer-Extractor/Tumble Dryer * Only available in gas HSA050N HSK050L HST050N...
Page 20
Introduction OPL Control Suffixes Control Digit (position 7) Actuation Digit (position 8) Example Control Suffix Combina- tion F - Dual Digital Control N - OPL FN- Dual Digital Control, OPL continues... Design Digit (Position 13) Tumble Dryer - 3, 5 and 6 Stacked Washer-Extractor/Tumble Dryer - 1 and 2 continues...
Preliminary Information Preliminary Information About the Control Glossary of Terms This control is an advanced, programmable computer that al- The following are a few terms and abbreviations to learn. lows the owner to control most machine features by pressing a These are referred to throughout the instructions.
Control Identification Control Identification Select Cycle Keypads H Models The SELECT keypad is used to select the specific machine cy- cle. The default cycle is set at the previously selected cycle. The selected cycle is indicated by the light (LED) on the con- trol.
Page 23
Control Identification U Models P Models TMB1785R_SVG TMB1787R_SVG 1. Display 1. Display 2. 7-segment Digits 2. 7-segment Digits 3. Increase/Decrease COOL DOWN TIME 3. Increase/Decrease COOL DOWN TIME 4. START (enter) Keypad 4. START (enter) Keypad 5. REVERSING Keypad 5. REVERSING Keypad 6.
Display Identification Display Identification Light Emitting Diodes (LEDs) REVERSING LED (reversing models only) Any time a cycle or cycle step is set for reversing, the RE- LIGHT EMITTING DIODES (LEDs) are used to indicate the VERSING LED will be lit. chosen cycle and cycle status.
Special Features Special Features Collecting Audit Information pads, the owner may perform diagnostic tests. For detailed information on running diagnostic tests, refer to The control will store audit information in its memory that can Manual Diagnostic Mode Menu . be retrieved by pressing various combinations of keypads. The control will record total machine cycles, total hours run and to- Rapid Advance Feature tal rapid advance cycles.
Machine Operation Machine Operation Power Up tions occurs, the control reverts back to Start Mode . If enough time elapses and the door is not opened or a keypad is pressed, the control will enter Extended Tumble Mode . When power is applied to the machine, the control becomes active and will display its machine type (td td), followed by the Changing Cycles...
Opening the Service Door Opening the Service Door Stacked Tumble Dryer IMPORTANT: If the service door circuit is broken or left in an open state, unauthorized people may gain access to programming. Open service door and disconnect bullet connector located be- tween the "white/black"...
Entering the Manual Mode Entering the Manual Mode Manual Mode allows audit and diagnostic control functions to 3. The display will shows rA Pd rA Pd. be accessed manually from the control. 4. Press the SELECT (∧) or the DISPLAY (∨) keypad to scroll through the options until the desired option appears in the How to Enter the Manual Mode display.
Rapid Advance Feature Rapid Advance Feature Manual Rapid Advance Menu 2. Press the SELECT (∧) or DISPLAY (∨) keypads to advance the cycle by reducing the time. This feature allows the user to quickly advance through a run- 3. Press the START (enter) keypad to select the desired time. ning cycle (reduce time remaining in the cycle).
Collecting Audit Information Collecting Audit Information Manual Read Audit Mode Menu 5. Simultaneously press the SELECT (∧) and DISPLAY (∨) keypads to return to the Manual Mode menu. The Manual Read Audit Mode menu allows an operator to view the audit data listed in Table 2 . Display Description 1.
Machine Diagnostic Functions Machine Diagnostic Functions Manual Diagnostic Mode Menu 4. Press the SELECT (∧) or DISPLAY (∨) keypads to scroll through the diagnostic test option steps. The Manual Diagnostic Mode allows an operator to run diag- 5. Press the START (enter) keypad to run the diagnostic test. nostic tests on various machine operations (refer to Table 3 ) NOTE: Press the SELECT (∧...
Machine Diagnostic Functions Test Number Diagnostic Mode Display Machine Configuration #5 Display Test d 33 d 33 EX XX EX XX d 34 * ICM Alarm Status (gas models only) d 34 A on A on, AoFF AoFF d 35 * ICM Reset Test (gas models only) d 35 rS Et...
Machine Diagnostic Functions Ignition Control Software Version Number d d Lint Door Switch Input Test d 16 d 16 05 (gas models only) This test will display whether the lint door switch is open or closed. To start test, control must be in the Manual Diagnostic This option displays the current ignition control software ver- Mode Menu .
Machine Diagnostic Functions To exit the test, simultaneously press the SELECT (∧) and Configuration Value Description DISPLAY (∨) keypads. T30 Pound Stack Tumble Machine Configuration #1 Display Test d 29 d 29 Dryer and 030 Stacked Wash- er-Extractor/Tumble Dryer This option shows the machine configuration values. To start test, control must be in the Manual Diagnostic Mode Menu .
Machine Diagnostic Functions *OFF = Fahrenheit, ON = Celsius **OFF = 120 VAC, ON = 240 VAC continues... Table 6 Machine Configuration #5 Display Test d 33 d 33 Config Value Adjust Fan 480V Motor Dri- Speed for Heat This option shows the voltage configuration of the machine Type and the fan speed type.
Machine Diagnostic Functions Cabinet Limit Thermostat Config Value Adjust Fan 480V Motor Dri- The display will show C oP C oP if sensed open for at least 1.5 sec- Speed for Heat onds and C CL C CL if sensed closed for at least one second. Type Stove Limit Thermostat 1 Eco Electric...
Machine Diagnostic Functions To start test, control must be in the Manual Diagnostic Mode Menu . Drive Motor Test d 40 d 40 To enter, press the START (enter) keypad. The display will show Fr d Fr d when spinning in forward direction, PA US PA US when the cylinder is paused and rE v rE v when spinning in the reverse...
Factory Test Cycle Factory Test Cycle The Factory Test Cycle allows the user to view machine details Test and Pressure Sensor Test. Refer to Factory Test Quick and run the machine through various cycle steps. Refer to Reference Chart for all steps in the Factory Test. Table 8 .
Page 49
Factory Test Cycle Factory Test Cycles Display Test Mode Comments All LEDs and display segments will light Show Entire Display Mode This mode will light all display elements and sound the audio. S oP or S CL Service Door Switch Test oP signifies the service door switch is S oP S CL...
Error Codes Error Codes Following is a list of possible error codes for an electronic NOTE: Fatal Errors will show out ordr along with out oF oF ordr control. the error on the display. Error Codes Display Description Cause/ Corrective Action Airflow Switch Bounces Inspect lint screen and ductwork.
Page 51
Error Codes Error Codes Display Description Cause/ Corrective Action Shorted Thermistor Error Remove any lint build-up around thermis- E SH E SH tor. If problem persists, replace control or thermistor. Airflow Switch Failed to Open Inspect lint screen and ductwork. Wipe EA F1 EA F1 clean and completely dry off the airflow...
Page 52
Error Codes Error Codes Display Description Cause/ Corrective Action Fan or Cylinder Motor IPM Overtemp Er- IPM temperature is detected too high. EF 06 EF 06, Ed 06 Ed 06 Check that heat sink on the motor(s) is clear of lint or any other obstruction and check that cylinder spins freely when empty.
Page 53
Error Codes Error Codes Display Description Cause/ Corrective Action Ed 16 (Tumble Dryer Design 6) Power Fail NO Dangerous Error Check voltage to machine and voltage to EF 16 EF 16, Ed 16 inverter drive. Ed 18 (Tumble Dryer Design 6) Fatal IPM Over Current Shunt Error Check motor wiring.
Page 54
Error Codes Error Codes Display Description Cause/ Corrective Action ICM Alarm Reset Shorted Error Check wiring between the I/O board and Eg 02 Eg 02 the ignition control. Power down and power up machine to clear the error. ICM Hardware Failure Error Ignition control has detected a hardware Eg 03 Eg 03...
