Tumble Dryer

OPL Electronic Control
Refer to Page 3 for Model Identification
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
Part No. 70444901R3
www.comlaundry.com
July 2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 70444901R3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alliance Laundry Systems 70444901R3

Summary of Contents for Alliance Laundry Systems 70444901R3

  • Page 1: Tumble Dryer

    Tumble Dryer OPL Electronic Control Refer to Page 3 for Model Identification Keep These Instructions for Future Reference. (If this machine changes ownership, this manual must accompany machine.) Part No. 70444901R3 www.comlaundry.com July 2011...

  • Page 3: Table Of Contents

    All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. 70444901 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Introduction... Model Identification ...
  • Page 4 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Testing Machine and Electronic Control Functions... 27 How to Enter Testing Feature ... 27 How to Start Tests... 27 How to Exit Testing Feature ... 27 Diagnostic Test Descriptions... 29 Control Software Version Number Test ...

  • Page 5: Introduction

    HT035N CHD35G2-CU035N HU035L Pound DR35G2-BA035N HU035N DR35G2-BA035L IPD35G2-IT035L DR35G2-BT035N IPD35G2-IT035N DR35G2-BT035L SA035L DR35G2-BU035N SA035N © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70444901 Introduction Steam/Thermal Oil ST025L CHD25S2-CU025S ST025N CHD25S2-CT025S SU025L DR25S2-BT025S SU025N DR25S2-BU025S UA025L HT025S...
  • Page 6 Pound DR80G2-BA075L IPD75G2-IT075L DR80G2-BT075D IPD75G2-IT075N DR80G2-BT075L SA075L DR80G2-BT075N SA075N DR80G2-BU075N ST075D DR80G2-BU075L ST075L © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT (Continued) Steam/Thermal Oil SAT45L SAT45N STT45D STT45L STT45N Not Applicable SUT45L SUT45N ST050D CT050S ST050L...

  • Page 7: Nameplate Location

    Includes models with the following control suffixes: EO – OPL electronic Nameplate Location The nameplate is located on the back of the machine and is programmed in the Control. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70444901 (Continued) Steam/Thermal Oil ST120L...

  • Page 8: Preliminary Information

    © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Audit Information The control collects and stores audit information, which can be accessed with a PDA or PC.

  • Page 9: Restore To Factory Defaults

    **Only available on units equipped with reversing feature. ***Only available on units equipped with moisture sensing feature. Refer to Factory Defaults, Menu section for information on Restoring Factory Defaults. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70444901...

  • Page 10: Control Identification

    H Models PROGRAM REVERSING ENERGY HEATING SAVER BACK Figure 2 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT U Models B, C, and I Models STOP START TMB1345R NOTE: The reversing feature is not available on all STOP models.
  • Page 11 LED will light up when a Moisture Dry or Auto Dry cycle is running. ENERGY SAVER LED will light up when the machine is in the heat portion of the cycle. HEATING © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70444901 Description Description...

  • Page 12: Operation Modes

    Pause Mode if loading or lint door opens. Press Start ( ) to Rapid Advance. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Rapid Advance Mode If the Rapid Advance Option is enabled, the user can...

  • Page 13: Communication Mode

    Mode. This mode is exited when the door is opened or Stop ( ) keypad is pressed. The control will then return to Idle Mode. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70444901 Control Identification Extended Tumble Mode The Extended Tumble Mode has two portions.

  • Page 14: Machine Cycle Definition And Operation

    © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Rotation Sensor Equipped Machines On machines equipped with a rotation sensor, the control monitors the rotation sensor to verify the cylinder is rotating.

  • Page 15: Entering The Manual Mode

    6. To exit, press the Back ( ) keypad. The control will revert back to Idle Mode. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70444901 Manual Programming can only be turned on or off with an external device.
  • Page 16 Manual Read Audit “rESEt” Manual Reset “diAg” Diagnostic Tests © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT To enter a programming option, press the Start ( keypad. To exit, press the Back keypad. Press the Start ( “Prog”...

  • Page 17: Programming Control

    5 “” Segment 1 6 “” Segment 2 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70444901 How to Program a Cycle 1. Press the Up ( ) or Down ( ) keypad to scroll through the option list.
  • Page 18 Global Temperatures “ ” Global Very Low Temperature “ ” Global Low Temperature “ ” Global Medium Temperature © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Default Description Value 100°F/38°C 70°-110°F/21°-43°C 7 (120) 0 (6) 120°F/49°C 100°-120°F/38°-49°C 140°F/60°C 120°-140°F/49°-60°C (50, 75, 120, 170...
  • Page 19 “ ” Year “ ” Daylight Saving “” Manual Rapid Advance “” Manual Diagnostics © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70444901 Default Description Value 190°F/88°C 160°-190°F/71°-88°C (35, T45, 55, 50, 75, Programming Control Value Range 120, 170 Pound Models), 155°-190°F/68°-...
  • Page 20 Down ( ) keypad to scroll through the programmable options. continued © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT To enter a programming option, press the Start ( keypad. To exit, press the Back “CyCXX”...
  • Page 21 Down ( ) keypad to scroll through the programmable options. continued continued © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70444901 To enter a programming option, press the Start ( keypad. To exit, press the Back keypad.
  • Page 22 Down ( ) keypad to scroll through the programmable options. continued © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT To enter a programming option, press the Start ( continued keypad. To exit, press the Back keypad.
  • Page 23 “Cd-” Global Cool Down continued © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70444901 To enter a programming option, press the Start ( keypad. To exit, press the Back keypad.
  • Page 24 “tEnp-” Global Temperatures continued © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT To enter a programming option, press the Start ( keypad. To exit, press the Back “rEv-” keypad.
  • Page 25 External Signal Multi-Segment Cycles Advanced Moisture (Enable/Disable) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70444901 To enter a programming option, press the Start ( continued keypad. To exit, press the BACK “Avdio-”...
  • Page 26 Press the Up ( ) or the Down ( ) keypad to scroll through the programmable options. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT To enter a programming option, press the Start ( keypad. To exit, press continued the BACK “t FC”...

  • Page 27: Collecting Audit Information

    Average Time from End of Cycle to Run  Mode (Last 25 Cycles) Table 2 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70444901 2. Once the desired option appears in the display, press the Start ( audit count.

  • Page 28: Manual Reset

    Once the program has been reset, the control will revert back to the Manual Mode, displaying  “ ”. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Manual Reset 70444901...

  • Page 29: Testing Machine And Electronic Control Functions

    “ ” Moisture Sensor Test (Resistance test jumper)* * = Tests only shown if enabled by the DIP switch configuration. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70444901 3. Press the Start ( ) keypad. Display will ...
  • Page 30 Press the Up ( ) or the Down ( ) keypad to scroll through the Diagnostic Test options. Moisture Sensor Test (Resistance) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT “dSoft” “ddoor” Loading Door Status “dLint”...

  • Page 31: Diagnostic Test Descriptions

    To exit the Lint Door Test, press the Back ( ) keypad. The control will return to the testing mode. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70444901 Testing Machine and Electronic Control Functions...

  • Page 32: Dip Switch Status

     Reset Test. If “ ” shows on the display, ICM Reset output is active. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Table 4 External Alarm Test This option tests whether the external alarm is working.

  • Page 33: Tumbler On Temperature Test

    ”. To exit this test, press the Back ( ) keypad. The control will return to the testing mode. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70444901 Testing Machine and Electronic Control Functions Machine Configuration Display #2 Test This option shows the machine configuration values for the machine type.

  • Page 34: Machine Configuration Display #3 Test

    To exit Airflow Switch Test, press the Back ( ) keypad. The control will return to the testing mode. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Fan Motor Test This option shows the fan motor running.

  • Page 35: Production Test Cycle

    NOTE: If power to the control is turned off before 10 Minute Test Cycle has ended, the cycle will be cleared from control. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70444901 Testing Machine and Electronic Control Functions 4.

  • Page 36: Machine Errors

    Idle Mode. This error will cause the corresponding Open Thermistor Audit Counter to be incremented and is saved in the Last Eight Alarms Menu. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Machine Errors Shorted Thermistor Error Any time the control senses a temperature greater than 210 + 4 °F during an active cycle, the control will...

  • Page 37: Auto Ignition Retry (Gas Models Only)

    Switch 1 error counter will be incremented and the error will also be saved to the Last Eight Alarms Menu. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70444901 Airflow Switch Does Not Close After Cycle...

  • Page 38: Fan Motor Contactor Error

    Fan Motor Centrifugal Switch error counter and will be saved in the Last Eight Alarms Menu. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT DIP Switch/Harness Index Mismatch Error On power up the control reads the Temperature Index...

  • Page 39: Error Codes

    Airflow Switch Error (Switch Does Not Close After Cycle Starts)   Airflow Switch Error (Switch Bounces During Cycle) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70444901 Error Codes  ” refer to Communication failure. Re-aim external device and try again.
  • Page 40   Fan Motor Centrifugal Switch Error  Moisture Sensor Error © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Table 8 (continued) Corrective Action Check heating connections, cycle power to machine. Remove any lint build-up around thermostat. If problem persists, replace control or thermostat.

  • Page 41: Communications Mode

    If an error occurs that terminates communication, the display will show the appropriate error code. NOTE: The Infra-red Communications option must be turned on. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70444901...

  • Page 42: Copyright, Alliance Laundry Systems Llc – Do Not Copy Or Transmit

    - If machine does not have the moisture sensing option, the moisture sensing cycles in the table above are automatically changed to Auto-Dry cycle type with Dryness Level 0 (zero). © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Cycle Charts...
