Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
Stacked 30 Pound Capacity
Stacked 45 Pound Capacity
Starting Serial No. 0602004144
Refer to Page 3 for Model Numbers
www.comlaundry.com
Part No. 70400101R10EN
January 2012

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 602004144 and is the answer not in the manual?

Questions and answers

Related Manuals for Alliance Laundry Systems 602004144

Summary of Contents for Alliance Laundry Systems 602004144

  • Page 1 Tumble Dryers Keep These Instructions for Future Reference. (If this machine changes ownership, this manual must accompany machine.) Stacked 30 Pound Capacity Stacked 45 Pound Capacity Starting Serial No. 0602004144 Refer to Page 3 for Model Numbers www.comlaundry.com Part No. 70400101R10EN January 2012...
  • Page 3 These instructions must be posted in a prominent location. Step-by-step instructions of the above safety information must be posted in a prominent location near the tumble dryer for customer use. 70400101 (EN) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT MISE EN GARDE POUR VOTRE SÉCURITÉ, les informations de ce guide doivent être respectées afin de...

  • Page 4: Table Of Contents

    All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Introduction...

  • Page 5: Introduction

    IPD45STG2-ITT45L IPD45STG2-ITT45N Includes models with control suffixes: 3O – DX4 OPL 3V – DX4 vended 3X – DX4 prep for coin © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70400101 (EN) Introduction Steam CHD30STS2-CTT30S CHD30STS2-CUT30S DRST30S2-BTT30S...

  • Page 6: Customer Service

    Model and serial numbers are found on serial plate on the rear of machine and inside door. Refer to Figure 1. Serial Plate © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Wiring Diagram The wiring diagram is located in the upper junction or upper contactor box.

  • Page 7: Safety Information

    NOTE: The word “NOTE” is used to communicate installation, operation, maintenance or servicing information that is important but not hazard related. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70400101 (EN) Safety Information IMPORTANT: Warranty is void unless tumble dryer is installed according to instructions in the Installation Manual.

  • Page 8: Important Safety Instructions

    12. Always clean the lint filter daily. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 13. Keep area around the exhaust opening and adjacent surrounding area free from the accumulation of lint, dust and dirt.
  • Page 9 28. DO NOT operate the tumble dryer if it is smoking, grinding, has missing or broken parts. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70400101 (EN) 29. DO NOT bypass any safety devices.

  • Page 10: Operating Instructions

    NOTE: Activation of the emergency stop button stops all machine control circuit functions, but DOES NOT remove all electrical power from machine. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT WARNING Operating Instructions Step 1: Clean Lint Screen/Compartment Remove any accumulated lint from the lint screen and compartment.

  • Page 11: Control Instructions

    Start ( ) pad must be pressed. 3. When the cycle is complete, open door and remove laundry. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70400101 (EN) Figure 3 NOTE: This machine includes an anti-wrinkle/ extended tumble feature.

  • Page 12: Dual Digital Timer Control

    4. Press and release START button to start tumble dryer. Display will show minutes remaining before end of cycle. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Figure 4 NOTE: One touch drying is available for repetitive loads.
  • Page 13 30 seconds every 2 minutes for 1 hour OR until the loading door is opened. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70400101 (EN) Operating Instructions NOTE: This machine includes an anti-wrinkle/ extended tumble feature.

  • Page 14: Error Codes

    Bouncing Airflow Switch (Flashing) Airflow Switch Closed when Resuming Cycle (Solid) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT WARNING Definition • Check thermistor. Replace if inoperative. • Check wiring diagram between control and thermistor. Refer to wiring diagram for proper wiring.

  • Page 15: Single Drop Control

    Starting 20 minutes after a cycle ends, the cylinder will tumble for two minutes every hour without heat, up to 18 hours or until door is opened. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70400101 (EN) Figure 5 Preliminary Control Information...
  • Page 16 Airflow switch opened/closed 5 or more AF (Flashing) times in a running cycle. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT NOTE: To change dipswitch settings refer to Installation Manual. To Program a Short Test Cycle: 1.

  • Page 17: Dx4 Coin Control

    Middle Button 140°F (60°C) Right Button 176°F (80°C) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70400101 (EN) Figure 7 NOTE: Drying times will be dependent on the number of coins that are inserted in the coin slot.

  • Page 18: Dx4 Opl Control

    Middle Button 140°F (60°C) Right Button 176°F (80°C) © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Figure 8 IMPORTANT: To stop the tumble dryer at any time during the cycle, OPEN DOOR. To restart the tumble dryer, CLOSE door and press START button.

  • Page 19: Ignition Control Operation For Non-Ce Models

    When this occurs, the control must complete the same prepurge and ignition sequence specified above. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70400101 (EN) Operating Instructions Control Lockout When the control locks out, the gas valve will be closed and all requests for heat will be ignored.

  • Page 20: Ignition Control Operation For Ce Models

    If the three attempts at ignition fail, the ignition control will enter Lockout Mode. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Run Mode While in Run Mode the ignition control leaves the gas valve on, monitors the flame signal, and leaves the igniter off.
  • Page 21 Slow Red and Green Flashes Fast Red and Orange Flashes Diagnostic (DGN) LED Figure 9 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70400101 (EN) Flame Probe Tests Unexpected Presence of Flame The Unexpected Presence of Flame test is performed when no flame is expected.

  • Page 22: Maintenance

    Lint left in the lint compartment is drawn back onto the lint screen and will restrict airflow. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Maintenance WARNING c. Be sure the lint screen is not torn. If it is, replace immediately.
  • Page 23 • Whenever ground wires are removed during servicing, these ground wires must be reconnected to ensure that the tumble dryer is properly grounded. Blower Housing Thermistor © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70400101 (EN) WARNING Cabinet Thermostat...

  • Page 24: Monthly

    4. Check flow of combustion and ventilation air. 5. Check belt tension and condition. Replace worn or cracked belts. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT WARNING Bi-Annually 1. Check mounting hardware for any loose nuts, bolts or screws.

  • Page 25: Monthly Maintenance

    Lint buildup will act as an insulator, causing machine to overheat. Clean lint and debris buildup from blower to maintain proper airflow, avoid overheating and prevent possible vibration. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70400101 (EN) WARNING Maintenance W002R1...

  • Page 26: Quarterly Maintenance

    Check and clean steam coils, if applicable. Check flow of combustion and ventilation air. Check belt tension and condition. Replace worn or cracked belts. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT WARNING W002R1 70400101 (EN)

  • Page 27: Annual Maintenance

    Check seal and idler assembly for wear. Remove burner tubes and clean using water and a brush. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 70400101 (EN) WARNING Maintenance W002R1...

  • Page 28: Before You Call For Service

    For technical assistance, call (920) 748-3121. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Possible Reason – Corrective Actions Insert correct coin(s) or valid card if applicable.
