5. Click Next to continue. The WAN IP Settings screen displays.
Figure 5-4
6. Enter or select the WAN IP settings that are explained in the following table. Your ISP will
advise you which settings to use.
Table 5-4. WAN IP Settings
Setting
IP address
Enable NAT
PPP IP extension
Add Default Route
MTU
Advanced WAN Configuration
ADSL2+ Modem Router DM111PSPv2 User Manual
Description
Select a radio button for the IP address setting:
• Obtain an IP address automatically. The modem router acquires the IP
address automatically.
• Use the following IP address. Enter an IP address in the WAN IP Address
field.
Select this check box to enable NAT, which automatically assigns private IP
addresses (10.1.1.x) to LAN-connected devices.
Select this check box to enable the modem router to function in semi bridge mode.
This option is available only when the IP address is obtained automatically and
when NAT is disabled.
Select this check box to set the current PVC as the default route. If this check box
is deselected, the first PVC that was enabled is set as the default route.
The normal MTU (Maximum Transmit Unit) value for most Ethernet networks is
1500 bytes, or 1492 bytes for PPPoE connections. For some ISPs you might need
to reduce the MTU. This is rarely required, and should not be done unless you are
sure it is necessary for your ISP connection.
