ADSL2+ Modem Router DM111PSPv2 User Manual
3. Click Next to continue. The Connection Type screen displays.
Figure 5-3
4. Enter or select the Internet connection type settings that are explained in the following table.
Your ISP will advise you which settings to use.
Table 5-3. Internet Connection Type Settings
Setting
Protocol
Encapsulation
Type
Enable QoS
Enable 802.1Q
VLAN Tagging
5-4
Description
• PPP over ATM (PPPoA)
• PPP over Internet (PPPoE)
• IP over ATM (IPoA)
• Bridging
• LLC/SNAP (the default setting)
• VC MUX
Quality of Service (QoS) support is enabled by default.
This settings, which is available only in PPPoE and bridged mode, allows multiple
computers to share the same physical network.
v1.0, December 2008
Advanced WAN Configuration
