- Page 1 ORANGE SQUASH Users Manual...
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS For your protection, please read these safety instructions com- pletely before operating the appli- ance, and keep this manual for future reference. Carefully observe all warnings, pre- cautions and instructions on the appliance and described in the operating instructions supplied with the appliance. -
Page 3: Important
This manual will help you to items are included: effectively utilize the BBE • The BBE Orange Squash Orange Squash. Should you have any questions, please feel • The BBE Orange Squash free to contact us at 800-233- User’s Manual... - Page 4 Thank you and congratulations on your purchase of the BBE Orange Squash! The Orange Squash is a compressor pedal patterned after an old favorite that levels out louder signals while boosting lower signals to provide smooth sustain without degrading the original sound.
-
Page 5: Table Of Contents
CONTENTS Important Safeguards ……………………………………………………i Important …………………………………………………………………ii Product Features …………………………………………………………iii Controls and Connections ………………………………………………1 Battery Replacement ……………………………………………………2 Applications………………………………………………………………3 Service ……………………………………………………………………4 Maintenance………………………………………………………………4 Warranty …………………………………………………………………5 Specifications ……………………………………………………………6... -
Page 6: Controls And Connections
CONTROLS AND CONNECTORS DC POWER INLET Accepts any standard Indicates Orange 9VDC power supply. Squash is engaged. BIAS CONTROL VOLUME Regulates the amount CONTROL of compression. Regulates the amount of output. INPUT Plug in your guitar, bass or the previous instrument level output OUTPUT of your signal chain. -
Page 7: Battery Replacement
Carefully unplug battery without straining cables. Replace with fresh bat- tery in reverse order. Use a standard 9Volt battery. Battery life is about 300 hours. Unplugging the input to the Orange Squash will turn the unit off and conserve battery life. -
Page 8: Applications
APPLICATIONS We recommend placing the Orange Squash before your amplifier or any over- drive/distortion pedal for the most desirable effect, but please feel free to experi- ment Please Note: When using a BBE Sonic Stomp we recommend placing it last in the... -
Page 9: Service
SERVICE Should the Orange Squash ever require If this product was purchased outside of service we recommend that it be sent to the United States, please contact your our facility in California. Please contact local distributor. our Service Department at 800-233- 8346 extension 116 for a “Return... -
Page 10: Warranty
WARRANTY Warranty registration of the unit to BBE Sound, Inc. This warranty will be consider null and void by BBE is not necessary. It is strongly recommended that you Sound, Inc. if any of the following is found: retain a copy of the bill of sale for future reference. -
Page 11: Specifications
SPECIFICATIONS Input Impedance: …………………330k Ohms Output Impedance: ………………1K Ohm Hardwire Bypass……………………Yes Power Requirements: DC inlet:…………………+9VDC min. 200ma Battery Life: ……………300 hours Dimensions: ………………………3.7"(W) x 4.7"(D) x 1.8"(H) Shipping Weight: …………………3.3 lbs. Note: Due to continuing product improvement, specifications and design are sub- ject to change without notice. - Page 12 5381 Production Drive Huntington Beach, CA 92649 714-897-6766 • FAX 714-896-0736 www.bbesound.com covered by U.S. Patent 4,482,866 and other U.S. and foreign patents pending. BBE is the registered trademark of BBE Sound, Inc. rev.1 12/05...
