Summary of Contents for BBE WAH

  • Page 1 Owner’s Manual...
  • Page 2 “Halo” Inductor and is essential to its unique vocal- like qualities. Many players and collectors alike search high and low and pay a hefty premium for these vintage wah pedals. BBE reengineered and tuned the “Halo” inductor to create those sounds made famous by players like Clapton, Hendrix etc.

  • Page 3: Contents Checklist

    If any of these items are found to be damaged or missing, immediately contact the BBE dealer from whom the unit was purchased. We recommend reading this manual to familiarize yourself with all of the features of the Wah before using. Should you have any questions, please contact BBE at 800-233-8346.

  • Page 4: Installing Battery

    Installing Battery Pull the latch to the right with thumbnail to release the hinged battery compartment cover. Carefully unplug battery without straining cables. Unplugging the input to the Wah will turn the unit off and conserve battery life.

  • Page 5: Getting Started

    2. Output 3. On/Off L.E.D. effect status 4. Harmony control (Q) – Changes the shape of the wah so you can come tailor it to your tastes. Turning the control to the left will soften the effect and turning it to the right will accentuate the effect.
  • Page 6 Applications Example #1 Sonic A A m m p p I I n n s s t t Crusher Stomp* For the most natural effect we recommend that you place the Wah before any overdrive/distortion or amplifier.
  • Page 7 Stomp* For a more dramatic effect we recommend that you place the Wah after any overdrive/distortion effect. * When using a Sonic Stomp we recommend placing it last in the signal chain and as close to your amp as possible.
  • Page 8 Service There are no user serviceable parts inside. Should the Wah require service please contact our Service Department for a Return Authorization at: BBE Sound, Inc. 800-233-8346 Ext.116 For service outside of North America please contact your local distributor. For a listing of BBE Distributors log on to:...

  • Page 9: Technical Specifications

    Technical Specifications Input Impedance:––––––––––––120K Ohms Output Impedance: ––––––––––22K Ohm Bypass: ––––––––––––––––––––True Hardwire Power Requirements: DC inlet: ––––––––––––9VDC (- Tip) Battery Life: ––––––––200 hours Dimensions: ––––––––––––––––4.5"(W) x 10"(D) x 3"(H) Shipping Weight: ––––––––––––3.75 lbs. Please Note: Due to continuing product improvement, specifications and design are subject to change without notice.

  • Page 10: Warranty

    (5) years 5. The bill of sales indicates that the purchase date of from date of purchase from BBE Sound Inc. or from an the equipment is not within the warranty period.

  • Page 11: Important Safeguards

    Important Safeguards For your protection, please read these safety instructions completely before operating the appliance, and keep this manual for future reference. Carefully observe all warnings, precautions and instructions on the appliance and described in operating instructions supplied with the appliance. I I N N S S T T A A L L L L A A T T I I O O N N sold with the product.
  • Page 12 5381 Production Drive Huntington Beach, CA 92649 714-897-6766 Phone 714-896-0736 Fax • bbesound.com BBE is the registered trademark of BBE Sound, Inc. rev.1 12/07...
