- Page 1 GREEN SCREAMER Users Manual...
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS For your protection, please read these safety instructions com- pletely before operating the appli- ance, and keep this manual for future reference. Carefully observe all warnings, pre- cautions and instructions on the appliance and described in the operating instructions supplied with the appliance. -
Page 3: Important
This manual will help you to items are included: effectively utilize the BBE • The BBE Green Screamer Green Screamer. Should you have any questions, please feel • The BBE Green Screamer free to contact us at 800-233- User’s Manual... - Page 4 Thank you and congratulations on your purchase of the BBE Green Screamer! The Green Screamer is an overdrive pedal that pro- duces a dynamic range of smooth and warm overdrive tones associated with vintage tube amps. Features: • Vintage Overdrive Circuit •...
-
Page 5: Table Of Contents
CONTENTS Important Safeguards ……………………………………………………i Important …………………………………………………………………ii Product Features …………………………………………………………iii Controls and Connections ………………………………………………1 Battery Replacement ……………………………………………………2 Applications………………………………………………………………3 Service ……………………………………………………………………4 Maintenance………………………………………………………………4 Warranty …………………………………………………………………5 Specifications ……………………………………………………………6... -
Page 6: Controls And Connections
CONTROLS AND CONNECTORS DC POWER INLET Indicates Green Accepts any standard Screamer is engaged. 9VDC power supply. GAIN CONTROL LEVEL CONTROL Adjusts the gain of Regulates the amount input stage. of output. TONE CONTROL INPUT Adjust clockwise for Plug in your guitar, treble boost, counter bass or the previous clockwise for treble cut. -
Page 7: Battery Replacement
Carefully unplug battery without strain- ing cables. Replace with fresh battery in reverse order. Use a standard 9Volt battery. Battery life is about 300 hours. Unplugging the input to the Green Screamer will turn the unit off and conserve battery life. -
Page 8: Applications
APPLICATIONS We recommend placing the Green Screamer before your amplifier or after any overdrive/distortion pedal for the most desirable effect, but please feel free to experiment Please Note: When using a BBE Sonic Stomp we recommend placing it last in... -
Page 9: Service
SERVICE Should the Green Screamer ever require If this product was purchased outside of service we recommend that it be sent to the United States, please contact your our facility in California. Please contact local distributor. our Service Department at 800-233- 8346 extension 116 for a “Return... -
Page 10: Warranty
5. The bill of sales indicates that the purchase date defects in material and workmanship for a period of of the equipment is not within the warranty five (5) years from date of purchase from BBE Sound period. Inc. or from an authorized dealer. During this period,... -
Page 11: Specifications
SPECIFICATIONS Input Impedance: …………………1MEG Ohms Output Impedance: ………………1K Ohm Hardwire Bypass……………………Yes Power Requirements: DC inlet:…………………+9VDC min. 200ma Battery Life: ……………300 hours Dimensions: ………………………3.7"(W) x 4.7"(D) x 1.8"(H) Shipping Weight: …………………3.3 lbs. Note: Due to continuing product improvement, specifications and design are sub- ject to change without notice. - Page 12 5381 Production Drive Huntington Beach, CA 92649 714-897-6766 • FAX 714-896-0736 www.bbesound.com covered by U.S. Patent 4,482,866 and other U.S. and foreign patents pending. BBE is the registered trademark of BBE Sound, Inc. rev.1 12/05...
