BBE TREMOR Owner's Manual

Dual-mode tremolo
Hide thumbs
Table of Contents

Advertisement

Quick Links

Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TREMOR and is the answer not in the manual?

Questions and answers

Related Manuals for BBE TREMOR

Summary of Contents for BBE TREMOR

  • Page 1 Owner’s Manual...

  • Page 2: Features Include

    Thank you and Congratulations on your purchase of the Tremor! The Tremor is a Dual-Mode Tremolo that offers the flexibility of two independent speed controls, and utilizes an all-analog optical circuit to create the warm pulsating sounds associated with the “Vibrato” effect of sought-after vintage tube amps.

  • Page 3: Contents Checklist

    If any of these items are found to be damaged or missing, Please contact the dealer from which the unit was purchased. We recommend reading this manual to familiarize yourself with all of the features of the Tremor before using. Should you have any questions, please contact BBE at 800-233-8346 Ext.116.

  • Page 4: Installing Battery

    Installing Battery Pull the latch to the left with thumbnail to release the hinged battery compartment cover. Carefully unplug battery without straining cables. Replace with fresh battery in reverse order. Use a standard 9Volt battery. Battery life is about 100 hours. Unplugging the input to the Mind Bender will turn the unit off and conserve battery life.

  • Page 5: Getting Started

    Getting Started 1. Input 2. Output 3. Speed 1 control 4. Speed 2 control 5. Depth control 6. Speed 1/Speed 2 status LEDs 7. Speed 1/Speed 2 selector footswitch 8. On/Off footswitch 9. Power Supply Inlet (-9VDC) and status LED...
  • Page 6 We recommend that you place the Tremor into an amplifiers Effects Loop or after any overdrive/distortion for the most natural effect, but please feel free to experiment. *To add better definition and clarity when using the Tremor we recommend placing a BBE Sonic Stomp last in the signal chain.

  • Page 7: Sample Settings

    Sample Settings How Soon Is Now Crimson and Clover Speed-7.5, Depth-7 Speed-7.5, Depth-9 Fast Arpeggio Tremolo 50’s Tremolo Speed-9, Depth-5 Speed-7, Depth-4...
  • Page 8 Service There are no user serviceable parts inside. Should the Tremor require service please contact our Service Department for a Return Authorization at: BBE Sound, Inc. 800-233-8346 Ext.116 For service outside of North America please contact your local distributor. For a listing of BBE Distributors log on to:...

  • Page 9: Technical Specifications

    Technical Specifications Input Impedance:––––––––––––1MEG Ohms Output Impedance: ––––––––––1K Ohm Bypass: ––––––––––––––––––––True Hardwire Power Requirements: DC inlet: ––––––––––––9VDC (- Tip) Battery Life: ––––––––300 hours Dimensions: ––––––––––––––––3.7"(W) x 4.7"(D) x 1.8"(H) Shipping Weight: ––––––––––––1.8 lbs. Please Note: Due to continuing product improvement, specifications and design are subject to change without notice.

  • Page 10: Warranty

    Warranty Warranty registration of the unit to BBE Sound, Inc. is This warranty will be consider null and void by BBE not necessary. It is strongly recommended that you Sound, Inc. if any of the following is found: retain a copy of the bill of sale for future reference.

  • Page 11: Important Safeguards

    Important Safeguards For your protection, please read these safety instructions completely before operating the appliance, and keep this manual for future reference. Carefully observe all warnings, precautions and instructions on the appliance and described in operating instructions supplied with the appliance. I I N N S S T T A A L L L L A A T T I I O O N N sold with the product.
  • Page 12 5381 Production Drive Huntington Beach, CA 92649 714-897-6766 Phone 714-896-0736 Fax • bbesound.com BBE is the registered trademark of BBE Sound, Inc. rev.1 8/08...
