Summary of Contents for BBE SOUL VIBE
- Page 1 Owner’s Manual...
-
Page 2: Features Include
Thank you for your purchase of the Soul-Vibe! The Soul-Vibe was patterned after Shin-oi Electronics Uni-Vibe™*. Made popular in the late ‘60s and early ‘70s by such players as Jimi Hendrix, David Gilmour and Robin Trower. Features Include: •Speed and Intensity controls •On/Off LED pulses rate of Speed control (when effect on) •True Hardwire Bypass •5 Year warranty... -
Page 3: Contents Checklist
Contents Check List: • Soul-Vibe • Soul-Vibe Owner’s Manual • 9volt power adapter (North America Only) • 9volt battery If any of these items are found to be damaged or missing, please contact the dealer from which the unit was purchased. Installing Battery: Pull the latch to the left with thumbnail to release the hinged bat- tery compartment cover. -
Page 4: Getting Started
Getting Started 1. Input 2. Output 3. (On/Off) Footswitch 4. On/Off (Effect/Speed Status) L.E.D. 5. Speed control 6. Intensity control 7. Power Supply Inlet... - Page 5 Applications Sonic Mind A A m m p p I I n n s s t t Soul-Vibe Stomp Bender We recommend placing the Soul-Vibe before your amplifier or any overdrive/distortion pedal for a classic sound, but please feel free to experiment * When using a Sonic Stomp we recommend placing it last in the signal chain and as close to your amp as possible.
-
Page 6: Sample Settings
Sample Settings Breathe (Pink Floyd) SPEED INTENSITY Machine Gun (Jimi Hendrix) SPEED INTENSITY Bridge of Sighs (Robin Trower) SPEED INTENSITY INTENSITY Leslie Simulator SPEED INTENSITY INTENSITY... - Page 7 Internal Trim Control Inside the Soul Vibe is a trim- mer control that will change the frequency range of the Soul Vibe’s sweep. This is pre-set at the factory however should you feel the need to experiment we recom- mend marking the trim control with a marker to remember its original setting.
- Page 8 Service There are no user serviceable parts inside. Should the Soul-Vibe require service please contact our Service Department for a Return Authorization at: BBE Sound, Inc. 800-233-8346 Ext.116 For service outside of North America please contact your local distributor. For a listing of BBE Distributors log on to:...
-
Page 9: Technical Specifications
Technical Specifications Input Impedance:––––––––––––82k Ohms Output Impedance: ––––––––––1K Ohm Hardwire Bypass ––––––––––––Yes Power Requirements: DC inlet: ––––––––––––+9VDC min. 200ma Battery Life: ––––––––100 hours Dimensions: ––––––––––––––––3.7"(W) x 4.7"(D) x 1.8"(H) Shipping Weight: ––––––––––––1.8 lbs. Note: Due to continuing product improvement, specifications and design are subject to change without notice. -
Page 10: Warranty
Inc. is not necessary. It is strongly recommended This warranty will be consider null and void by that you retain a copy of the bill of sale for future BBE Sound, Inc. if any of the following is found: reference. 1. The equipment has been physically damaged. -
Page 11: Important Safeguards
Important Safeguards For your protection, please read these safety instructions com- pletely before operating the appliance, and keep this manual for future reference. Carefully observe all warnings, precautions and instructions on the appliance and described in the operating instructions sup- plied with the appliance. - Page 12 5381 Production Drive Huntington Beach, CA 92649 714-897-6766 • FAX 714-896-0736 bbesound.com BBE is the registered trademark of BBE Sound, Inc. rev.1 10/06...
