2. Remove the shipping key from the library. Carefully slide the library all the way back
until it makes contact with the small flanges at the back of the rails (see
Figure 7).
3. From the back of the rack, attach the library to the rails by inserting an M3 (the two
smaller screws) screw into each of the small flanges. Tighten the screws using a #2
Phillips screwdriver.
Tandberg StorageLibrary T24—
Figure 6 Attaching the Tandberg StorageLibrary T24 to the rails at the back of the rack
6 8
OF
Figure 7 and
Back of rack
M5 x 12 (black) screws
(total qty installed = 16)
(total qty shipped = 18)
Insert M3 x 8 screws here
(one on each side)
