Change the
orientation
Any magazine or magazine blank can be
configured to fit in the right or left
magazine bay.
2-cartridge opening on top
Change the orientation of a
cartridge magazine
a
Remove the two screws that attach the
handle to the front of the magazine
blank.
b
Unsnap the handle carefully, ensuring
you do not break the hinge.
Slide
c
Rotate the handle 180 degrees so that
what was the top of the handle is now
the bottom. (Procedure continues.)
Left magazine handle
Pull out
Right magazine handle
