- Page 1 E-RDA-PM “PowerMatic” indoor bicycle trainer instructions manual - 1 -...
- Page 2 SCHEMATIC R8-1 SR-13 Screw-M SR-12 ER-3 ER-1 SR-12 ER-10 M8-3 ER-7 M8-4 M8-4 ER-8 ER-23 SR-5 ER-12 Screw-L SR-14 SR-8 ER-24 ER-14 ER-13 ER-16 ER-17 Screw w/ washer ER-18 ER-19 ER-20 F-1 : Coupling (Right) ER-1 : Upper Case F-2 : Coupling (Left) ER-3 : Top Cover (blue)
- Page 3 • The trainer is manufactured to precise standards. Disassembly may void your warranty. • "Magturbo" and “RDA” are the trademarks of Minoura Co.,Ltd. and may not be copied. • "Magturbo" and “RDA” are the trademarks of Minoura Co.,Ltd. and may not be copied.
- Page 4 HOW TO SETUP YOUR E-RDA-PM TRAINER <Required Tools: M5 hex wrench> Open the frame support legs and fit the rubber feet at the correct angle so the base is in full contact with the floor. NOTE: If the both legs don’t touch the floor at same time and if one side of the leg is still slightly raised, pull up the leg upward strongly then place the trainer on the floor again.
- Page 5 Hold the bike firmly by hand and turn the right side hub handle clockwise until the coupling comes into contact with the right side skewer nut. Adjust each height of the Mag unit and the assistant roller to fit to your rear wheel perfectly and tighten the bolts firmly.
- Page 6 HOW TO INSTALL THE REMOTE LEVER You can install the remote lever on anywhere the diameter is between 22.2mm (7/8”) and 31.8mm (1-1/4”) like as on the handlebar. Fully loosen the knob bolt on the plastic holder until it stops then push down the bolt to open the holder. (see Fig.
- Page 7 ABOUT SLIPPAGE PROBLEM The pateneted roller system used in the rim drive models from Minoura is made to fit a wide variety of bicycles and wheels. Therefore, you should expect that sometimes the rollers will slip a little on your rims. This is com- pletely normal and due to the spring mechanism that provides a secure fit with such a large variety of bicycles and wheels.
- Page 8 If you train on a carpeted surface, consider using a rubber mat or a mat of other non-marking material to eliminate the possibility of marking the carpet by the trainer, bike, or bodily fluids. Minoura cannot be held responsible for any stain incurred while using a Minoura product.
