M80-R Schematics
(Remote version)
BF-3
LM-14
BF-4
BF-6
EM-1
EM-2
EM-11
LM-10
BF-3: M70/80 Main Frame (White)
BF-4: Leg Rubber Cover (Red)
BF-6: Leg Rubber
UF-6: Right Side Coupling & Clamp Lever
UF-7: Clamp Lever Guide
UF-8: Left Side Coupling
UF-9: Coupling Lock Ring (Red)
M5-2: Rubber Foot Cap (29mm)
MF-3: Micro Adjust Knob Set
LM-10: Base Plate
LM-14: Remote Shifter (Black)
UF-9
MF-3
EM-4
EM-3
EM-5
EM-9
UF-8
BF-4
BF-6
EM-6
EM-10
EM-1: Outer Cap
EM-2: Axle Holder
EM-3: Drive Roller & Bearing
EM-4: Main Housing
EM-5: Alloy Plate
EM-6: Magnet Plate (M70/80-R)
EM-9: Remote Base
EM-10: C able Guide
EM-11: Connecting Plate
EM-14: F lywheel (800g)
EM-15: F lywheel Cover (Transparent)
UF-6
EM-14
EM-15
UF-7
M5-2
