1. Maximum Resolution
2. Recommend Resolution
3. Synchronization Range
Horizontal
Vertical
4. Active Display Area
5. Dot Pitch
6. Support display colors
7. Contrast Ratio (Typical)
8.Luminance of White
9. Bandwidth
10. User Control
11. OSD Function
12. View Angle
CR=5
Horizontal
Vertical
13. Power Source
14. Power Consumption
15. Connection Type
16. Input Signal
Video
Sync.
17. Color Temperature
18. Dimension (WxHxD)
Set
19. Monitor Weight
20. Base Operation
Tilt
21. Power Saving
ON
STAND BY
OFF
22. Signal Connector Pin Assignment
Pin No.
23. Audio signal
B. SPECIFICATIONS
1280 x 1024 @ 75Hz
1280 x 1024 @ 60Hz
31 – 80 KHz
60– 75 Hz
376mm (H) x 301mm (V)
0.294(H) x 0.294(V) mm
16.7M color
600
250cd/m²
135MHz
4 Key Switch
Brightness, Conrast, H-Pos, V-Pos, H. Size, Phase, Color Select,
Auto, Reset, Language, OSD Adjust, Exit
85 , 85 Degrees
85 , 85 Degrees
100 – 240 Vac 60 / 50 Hz
60W (max.)
15 Pin D Type / DVI
Analog R.G.B. , 0.7Vp-p / 75 Ohms
TTL level,positive or negative polarity
Cool / Natural / Warm
Packing
484mm x 500mm x 150mm
420mm x 428mm x 170mm
7.3Kg / 6.1Kg
0 / + 15 degree
¡Õ 60W
¡Õ 5W
¡Õ 5W
1. Red
2. Green
3. Blue
4. Ground
5. Self Test
6. Red Ground
7. Green Ground
8. Blue Ground
3.5F stereo phone jack
2.5+2.5W
9. V
from PC for DDC
DD
10. Sync. Ground
11. Ground
12. SDA (For DDC)
13. Horizontal Sync.
14. Vertical Sync.
15. SCL (For DDC)
8O Speaker
