NO
Parts No.
65
382-392-032564
66
382-393-032564
67
382-473-032564
68
385-104-032584
69
409-003-0110
70
483-002-104S6
71
485-415-S070
72
485-D25-S118
73
506-0AI-C1084
74
506-0CS-5828
75
506-1LM-3485
76
506-524-LC21
77
506-5EN-29LV8
78
506-5NM-24C16
79
506-774-LCX14
80
506-774-LCX541
81
506-CPW-131A-20
82
506-RLD-1117-A
83
518-02N-3904
84
518-02N-3906
85
518-1CE-9435
86
522-030-B340-T
87
528-2BA-T54C
88
529-350-05R6
89
531-143-49US
90
558-352-5000
91
630-006-1008
92
630-008-C001
Description
SMD CC 0.039uF 25V X7R 0603
SMD CC 0.047uF 25V X7R 0603
SMD CC 0.047uF 25V X7R 0603
SMD CC 0.1uF 25V Y5V 0603
DC Jack 3.5D SCD510
Connector Pin Pitch 2.54mm 1*4 Pin
D-SUB 3R15 180D H6.8 Blue
DVI-D connector 11.40mm
SMD REG. AIC1084CM 3.3V 5A
SMD 85M LVDS CS5828+TQFP56
LM3485/NS MSOP-8
Memory IC 24LC21 SMD
Flash 8M EN29LV800T-70RTC/EON
Linear OC NM24C16M-8 (SMD)
SMD Hi Speed TTL 74LCX14
74LCX541 TSSOP-20 FAIRCHILD
Scaler IC PW131A-20Q
LD1117-ADJ-A UTC SOT223
TR. 2N3904 SMD
SMD TR 2N3906
MOSFET CE9435A CO8
SCHOTTKY SB340 TP
SMD Diode BAT54C SOT23
SMD Zener 5.6V MMSZ5232B
XTAL 14.318Mhz LC=16pF 49US
SMD Fuse 1206 24V 5A
Base 6P JWT A2001 Pitch 2
JST 1.5mm HEADER ZR S8B-ZR
Part Location
C22.,
C23.,
C24.,C25.,C27.,
C5.,C193.,C194.,C1.,C4.,C8.,C11.,C14.,
C15.,C16.,C20.,C21.,C30.,C31.,C32.,
C33.,C34.,C35.,C36.,C37.,C38.,C39.,
C40.,C41.,C42.,C43.,C44.,C45.,C46.,C47.,
C48.,C49.,C50.,C51.,C52.,C53.,C54.,
C55.,C56.,C57.,C58.,C59.,C60.,C62.,
C63.,C64.,C65.,C66.,C67.,C68.,C69.,
C70.,C71.,C72.,C73.,C74.,C76.,C77.,
C78.,C79.,C86.,C92.,C93.,C95.,C96.,
C98.,C100.,C102.,C105.,C108.,C111.,
C113.,C116.,C117.,C118.,C119.,C121.,
C126.,C127.,C131.,C199.,C200.,C201.,
CN3.,
J2.,
CN14.,
CN15.,
U14.,
U9.,U10.,
U13.,
U2.,U1.,
U6.,
U8.,
U3.,
U7.,
U4.,
U15.,U16.,
Q1.,Q2.,Q3.,Q4.,Q5.,Q7.,Q8.,Q9.,
Q10.,
U11.,U12.,U17.,
D14.,
D4.,D1.,
D15.,
Y1.,
F1.,
CN4.,
CN1.,
Q' ty
1
1
3
83
1
1
1
1
1
2
1
2
1
1
1
1
1
2
8
1
3
1
2
1
1
1
1
1
