Page 1: User Manual
7" Portable On-camera LCD Monitor User Manual DT-X71F Model: HDSDI&HDMI, Waveform, Audio meter, Focus assist DT-X71H HDSDI&HDMI DT-X71C HDMI Please read this User Manual throughout before using. - Page 2 Preface Congratulations on your purchase of this product. Please read this user manual carefully. 1． All internal technologies of this product are protected, including device, software and trademark. Reproduction in whole or in part without written permission is prohibited. 2． All brands and trademarks are protected and other relative trademarks in this user manual are the properties of their respective owners.
-
Page 3: Maintenance
Maintenance Monitor 1. Please keep the signal terminals and the cooling vent away from knife-edge, metal or liquid in order to avoid short-circuit and damage. 2. Please don't try to disassemble any parts of the monitor by yourself, which would probably damage the monitor and do harm to human body, and it will cause the invalidation of product warranty. - Page 4 1. Features DT-X71F ◆ New high resolution 7” LCD Panel ◆ Peaking focus assist (red/blue switch) 16:9, 1024×600, 16.77 million colors, 900:1 The Peaking focus assist function is to mark the contrast, and H160°/ V160°viewing angle. sharpest edges of the image with red or blue color, ◆...
- Page 5 ◆ Image Flip Set image to rotate by 180°. DT-X71C ◆ New high resolution 7” LCD Panel ◆ User definable function keys 16:9, 1024×600, 16.77 million colors, 900:1 contrast, and H160°/ V160°viewing angle.
-
Page 6: Front View
DT-X71F Front view ⑴ PHONE: Earphone jack ⑵ POWER: Power on/off Connect with power cable or mount battery, press the “POWER” and the power indicator is turned on and after 10 seconds, the monitor will be switched on and get into normal working status. Press the “POWER”... - Page 7 ⑵ TALLY Light: Red, Green and Yellow 3-color TALLY indicator ⑶ Battery mount: Connect with JVC battery BN-VF823 or SWIT battery BN-S8823 to power the monitor. ⑷ HDSDI IN1/2: HD/SD-SDI input (BNC connector) ⑸ HDSDI OUT: HD/SD-SDI loop through output (BNC connector) ⑹...
- Page 8 DT-X71H Front view ⑴ PHONE: Earphone jack ⑵ POWER: Power on/off Connect with power cable or mount battery, press the “POWER” and the power indicator is turned on and after 10 seconds, the monitor will be switched on and get into normal working status. Press the “POWER” again, the indicator is turned off and monitor is switched off.
- Page 9 ⑵ TALLY Light: Red, Green and Yellow 3-color TALLY indicator ⑶ Battery mount: Connect with JVC battery BN-VF823 or SWIT battery BN-S8823 to power the monitor. ⑷ HDSDI IN1/2: HD/SD-SDI input (BNC connector) ⑸ HDSDI OUT: HD/SD-SDI loop through output (BNC connector) ⑹...
- Page 10 DT-X71C Front view ⑴ PHONE: Earphone jack ⑵ POWER: Power on/off Connect with power cable or mount battery, press the “POWER” and the power indicator is turned on and after 10 seconds, the monitor will be switched on and get into normal working status. Press the “POWER”...
- Page 11 ⑴ DC 12V IN: Connect with DC12V 4-pin XLR power adapter. ⑵ Battery mount: Connect with JVC battery BN-VF823 or SWIT battery BN-S8823 to power the monitor. ⑶ VIDEO OUT: Composite video loop through output (BNC connector) ⑷ AUDIO L/R: Stereo audio L/R input (RCA connector) ⑸...
-
Page 12: Menu Operation
3. Menu Operation Press “MENU” and it will display menu system Revolve “OK” to select an item. The selected item will be highlighted display. Press “OK” to enter the selected item. Under menu system, press “MENU” to back to previous menu. ... - Page 13 6. OSD Settings Submenu The OSD Settings Submenu includes: ⑴ LANGUAGE: Menu language English / Chinese selection ⑵ H-POSITION: Menu horizontal position (0-100) adjustment, real-time preview, default value: 50, center. ⑶ V-POSITION: Menu vertical position (0-100) adjustment, real-time preview, default value: 50, center. ⑷...
- Page 14 The F KEY Settings Submenu is to define Function Keys on the front keyboard. The DT-X71F has 3 function keys: F1, F2 and F3; The DT-X71H and DT-X71C has 2 function keys: F1 and F2. The available function items of each model are:...
-
Page 15: Specifications
0℃～+40℃ Working humidity 10%～90% Storage temperature -15℃～+60℃ Storage humidity 10%～90% Dimensions 192×139×47mm Net weight 550g * DT-X71C doesn’t support SDI input. 12. Packing List ×1 1. Monitor ×1 2. User Manual ×1 3. Power adaptor ×1 4. Power cable ×1 5. - Page 16 This model is manufactured, warranted and supported by SWIT Electronics Co., Ltd. / SWIT Electronics USA, LLC, and distributed in North America by JVC Professional Video Products. To obtain service or for further information, please contact: SWIT Electronics USA, LLC.
