Directed Electronics ProSecurity SR6000 Installation Manual page 39

■ Pressing
a fourth time within five seconds: The siren chirps four times followed by a long chirp.
Zones Two and Four are now bypassed.
■ Pressing
a fifth time within five seconds: The siren chirps five times followed by a long chirp. All
input zones, except the ignition, are now bypassed.
s s y y s s t t e e m m f f e e a a t t u u r r e e s s l l e e a a r r n n r r o o u u t t i i n n e e
The System Features Learn Routine™ dictates how the unit operates. Due to the number of features, the
features have been divided into three menus. It is possible to access and change any of the feature set-
tings using the Valet®/Program switch. However, this process can be greatly simplified by using the ProSecurity
Programmer. Any of the settings can be changed and then assigned to one of up to four transmitters, a feature
called Owner Recognition. Each time that particular transmitter is used to disarm the system, the assigned
feature settings will be recalled. Owner Recognition is only possible when programming the unit via the
ProSecurity Programmer.
The learn routine may be locked if previously programmed using the ProSecurity Programmer. If the horn
generates one long honk when attempting to program the unit, the learn routine is locked and must be
unlocked using the ProSecurity Programmer before proceeding.
T T o o p p r r o o g g r r a a m m t t h h e e f f e e a a t t u u r r e e s s u u s s i i n n g g t t h h e e V V a a l l e e t t s s w w i i t t c c h h : :
1. O O p p e e n n a a d d o o o o r r . . (The GREEN wire, H1/5, or the VIOLET, H1/7 must be connected.)
2. K K e e y y . . Turn the ignition on and then back off.
3. S S e e l l e e c c t t M M e e n n u u . . Press and H H O O L L D D the Valet®/Program switch. When the LED flashes once and
the siren chirps, Menu One has been selected. Continue to hold the switch until the LED
flashes twice and the siren chirps twice, Menu Two has now been selected. Continue to
hold the switch until the LED flashes three times and the siren chirps three times, Menu
Three has now been selected. Release the switch after the Menu choice has been selected.
4. C C h h o o o o s s e e . . Within 10 seconds, press and release the Valet®/Program switch the number of
times corresponding to the feature number you want to program and then press and hold
the switch. (See Feature Menus .)
After a second, the LED will flash to indicate which feature you have accessed. For example, in Menu Two, groups
of eight flashes would indicate access to the activation pulse setting (Feature 2-8). The horn will also honk eight
times (if connected).
