c.
Configure port 20 as a member of VLAN 10 and port 21 as a member of VLAN 20. Enable each VLAN.
d.
Click Submit.
2.
Configure the following client and server interfaces:
IF 1
IP address = 192.168.1.100
Subnet mask = 255.255.255.0
VLAN 10
IF 2
IP address = 10.10.12.1
Subnet mask = 255.255.255.0
VLAN 20
IF 3
IP address = 10.10.12.1
Subnet mask = 255.255.255.0
IF 4
IP address = 10.10.12.1
Subnet mask = 255.255.255.0
a.
Open the IP Interfaces folder, and select Add IP Interface.
High availability 152
