Displaying the entire image during DIGITAL
ZOOM operations
Use this function to display the entire image within the
sub screen together with an enlarged image on the main
screen.
Example: Setting "ZOOM NAV" to "S BY S"
On "ZOOM NAV" of "FUNCTION" menu, select "S BY
S".
FUNCTION
POWER MGT.
INPUT SKIP
SUB. P DETECT
ZOOM NAV
PICTURE FREEZE
PDP SAVER
SEL.
ADJ.
Information
ZOOM NAV Function
* This feature is available only for RGB1 or RGB2 input
signals.
* This feature does not function during multi screen mode.
* This feature does not function while PICTURE FREEZE
is operating.
* Providing a 2-screen display will cancel this function.
ZOOM NAV settings
OFF: Will not show the entire image on the sub screen.
S BY S: Will show the entire image on the sub screen
of side-by-side mode.
BTM LEFT~TOP LEFT: Will show the entire image
on the sub screen of picture-in-picture mode.
Side-by-Side
RGB/PC1
Zoom+/- button
SINGLE button
: OFF
: OFF
: AUTO
: S BY S
: S BY S1
: MANUAL
EXIT RETURN
Picture-in-Picture
RGB/PC1
E-25
4-29

Displaying still images in the sub screen

This feature enables display in the sub screen of still images
captured by pressing the ACTIVE SELECT button.
Example: Setting "PICTURE FREEZE" to "BTM
LEFT"
On "PICTURE FREEZE" of "FUNCTION" menu, select
"BTM LEFT".
FUNCTION
POWER MGT.
INPUT SKIP
SUB. P DETECT
ZOOM NAV
PICTURE FREEZE
PDP SAVER
SEL.
ADJ.
Information
PICTURE FREEZE Function
* This feature is available only for RGB1 or RGB2 input
signals.
* This feature does not function during multi screen mode.
* Digital zoom is not available while this function is
operating.
* A further press of the ACTIVE SELECT button while
this function is operating will cancel this function.
* Providing a 2-screen display will cancel this function.
PICTURE FREEZE settings
OFF: Will not show the still image.
S BY S1, 2: The still images captured by pressing the
ACTIVE SELECT button will be shown on the sub
screen of side-by-side mode.
BTM LEFT~TOP LEFT: The still images captured by
pressing the ACTIVE SELECT button will be shown
on the sub screen of picture-in-picture mode.
Side-by-Side
RGB/PC1
ACTIVE
SELECT
button
S BY S1
RGB/PC1
RGB/PC1
or
S BY S2
RGB/PC1
RGB/PC1

Reducing burn-in of the screen

The brightness of the screen, the position of the picture,
positive/negative mode and screen wiper are adjusted to
reduce burn-in of the screen.
On "PDP SAVER" of "FUNCTION" menu, select
"MANUAL", then press the MENU/ENTER button.
The "PDP SAVER" screen appears.
: OFF
: OFF
: AUTO
: BTM LEFT
: BTM LEFT
: MANUAL
EXIT RETURN
Picture-in-Picture
RGB/PC1
ACTIVE
SELECT
button
RGB/PC1
RGB/PC1
