PRACTICAL USER'S GUIDE
FOR THE IN-STUD FIREPLACE
MODEL NUMBER:
V1525BT
V1525RT
Serial Number _______________
Model Number _______________
Valued Customer,
We are pleased that you have chosen to purchase an
electric fireplace manufactured by Dimplex North America
Limited.
Over the years, valuable memories will occur around the
warmth and comfort of your hearth. Thank you for allowing
our product to be the backdrop for those special moments.
Quality checked by:
7208630100R01

Advertisement

Table of Contents
loading

Related Manuals for Dimplex IN-STUD V1525BT

Summary of Contents for Dimplex IN-STUD V1525BT

  • Page 1 Model Number _______________ Valued Customer, We are pleased that you have chosen to purchase an electric fireplace manufactured by Dimplex North America Limited. Over the years, valuable memories will occur around the warmth and comfort of your hearth. Thank you for allowing our product to be the backdrop for those special moments.
  • Page 2 See page 4 for an illustration on how to locate the rating plate. 4. If you have any questions or concerns regarding the operation of your fireplace, contact Dimplex customer service at 1-888-DIMPLEX (1-888- 346-7539) CONTENTS PAGE 1 –...
  • Page 3 Contact Dimplex Customer Services 1-888-346-7539 immediately. 6. Do not use outdoors. 7. Never locate heater where it may fall into a bathtub or other water container.
  • Page 4 9. To disconnect the unit, turn the controls off, and then remove the plug from the outlet or switch off at main power supply panel if the unit is hardwired. 10. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause an electric shock or fire, or damage to the heater.
  • Page 5 SAVE THESE INSTRUCTIONS If you have any questions about our products please have the product model and serial numbers available upon calling Dimplex customer service. To locate the model and serial number see below.
  • Page 6 NOTE: Procedures and techniques that are considered important enough to emphasize. CAUTION: Procedures and techniques, which, if not carefully followed, will result in damage to the equipment. WARNING: Procedures and techniques, which, if not carefully followed, will expose the user to the risk of fire, serious injury, illness or death.
  • Page 7 Remove glass assembly before installing fireplace on or into a wall. 1. Remove screws securing glass assembly on the mounting tabs. (Figure 1) 2. Use both handles on the sides of the glass assembly, lift and remove the assembly from the fireplace.
  • Page 8 Figure 2 NOTE It is recommended that the bottom of the unit not be mounted higher than 48" from the ground to maintain an optimized viewing angle of the flame. CAUTION The fireplace must be mounted at two points, one of which must be on a wall stud.
  • Page 9 Air Circulation 3. With a wall stud finder, locate the center of the wall stud, drive a wood screw into stud and leave approximately 1/8" exposed threads for the fireplace to hang on. 4. The second mounting point should be picked such that it is farthest (to the left or right) relative to the first one among the seven keyholes (A to G shown in figure 2) on the...
  • Page 10 tool to install a threaded drywall anchor as the drywall may distort, tear or slightly buckle as a result of over-torque. 6. With a Philip’s head screw driver, screw that drywall anchor screw into the drywall anchor already in the wall, leave about 1/8" exposed threads for mounting the fireplace.

  • Page 11: Built-In Instructions

    Dimplex North America will not be responsible for inaccuracies in the design or manufacture of enclosures.
  • Page 12 WARNING Ensure method of installation does not obscure the air intake slots on bottom of unit in any manner. Keep minimum 4" clearance from bottom of unit to any surface such as the top of a cabinet. 3. Wire a dedicated, properly fused circuit with 120V, 15amp rating.
  • Page 13 7. Route the power supply wire through the knockout on supplied alternative junction box cover and secure with a wire clamp (not supplied) (FIGURE 7.) 8. Connect the black wire (live) from the unit to the black wire from power supply. (FIGURE 7.) 9.

  • Page 14: Bathroom Installation

    Figure 8 13. Attach fireplace frame as shown in figure 4. Bathroom Installation This firebox must be protected by a GFI receptacle or circuit for bathroom use. If receptacle is used it must be readily accessible. This unit is an electrical appliance that is not watertight and must be installed as to prevent water from entering the unit to prevent electrical shock.

  • Page 15: Operation

    Operation The controls are located on the right hand side of the fireplace. Figure 9. A. MAIN ON/OFF SWITCH Thermostat Heater ON/OFF Switch Main ON/OFF Switch Figure 9 The switch has two ON positions marked and “ON”. The “ON” position is for manual operation. In this position the built-in remote control is by-passed.

  • Page 16: Resetting The Temperature Cutoff Switch

    Main ON/OFF switch to OFF and waiting 5 minutes before switching the unit back on. CAUTION If you need to continuously reset the heater, disconnect power and call Dimplex customer service at 1-888- DIMPLEX (1-888-346-7539). Remote Operation The Fireplace is supplied with an integrated on/off...

  • Page 17: Maintenance

    Battery Replacement To replace the battery, slide battery cover open on the hand held transmitter. Install one 12-volt (A23) battery in the battery holder. Close the battery cover. Off Button On Button Maintenance WARNING Disconnect power before attempting any maintenance or cleaning to reduce the risk of fire, electric shock or damage to persons.
  • Page 18 Helpful Hints It is a good idea to replace all light bulbs at one time if they are close to the end of their rated life. Group replacement will reduce the number of times you need to open the unit to replace light bulbs. Light Bulb Requirements Quantity of two 40W Chandelier or candelabra bulbs with E-12 (small) socket base, 120 Volt.

  • Page 19: Glass Cleaning

    Light Block Figure 11 Glass Cleaning The front glass is cleaned in the factory during the assembly operation. During shipment, installation, handling, etc., the front glass may collect dust particles, these can be removed by dusting lightly with a clean dry cloth. To remove fingerprints or other marks, the glass can be cleaned with a damp cloth.
  • Page 20 Products covered by this limited warranty have been tested and inspected prior to shipment and, subject to the provisions of this warranty, Dimplex warrants such products to be free from defects in material and workmanship for a period of 12 months from the date of the first purchase of such product.
  • Page 21 What you must do to get service under this limited warranty Defects must be brought to the attention of Dimplex Technical Service by contacting Dimplex at 1-888-DIMPLEX (1-888-346- 7539), or 1367 Industrial Road, Cambridge Ontario, Canada N1R 7G8.
  • Page 22 (or any replacement product or part) or any labour or transportation costs. Such costs shall be the purchaser’s responsibility. What Dimplex and its dealers and service agents are also not responsible for: IN NO EVENT WILL DIMPLEX, OR ITS DIRECTORS,...
  • Page 23 The provisions of the United Nations Convention on Contracts for the Sale of Goods shall not apply to this limited warranty or the sale of products covered by this limited warranty. 1-888-DIMPLEX 1-888-346-7539 1367 Industrial Road Cambridge, Ontario...
