Installing IPS-4240-DC
Strip the ends of the wires for insertion into the power connect lugs on IPS-4240-DC.
Step 8
1
2
Insert the ground wire into the connector for the earth ground and tighten the screw on the connector.
Step 9
Using the same method as for the ground wire, connect the negative wire and then the positive wire.
1
2
1
Negative
2
Positive
3
Ground
4
On/Off Switch
Installing Cisco Intrusion Prevention System Appliances and Modules 6.2
2-12
+
3
4
+
3
4
5
Negative
6
Positive
7
Ground
Chapter 2
Installing IPS-4240 and IPS-4255
7
6
5
+
OL-15638-01
