Chapter 4
Installing the ASA 5505
Figure 4-2
1
Connect the other end of the Ethernet cable to a device, such as a router, desktop
Step 3
computer, or printer.
Note
78-18003-02
Connecting to an Ethernet Interface
POWER
48
VDC
7
6
POWER over ETHERNET
5
Ethernet switch ports
When connecting a computer to an inside port on the rear panel of the
adaptive security appliance, use a straight through cable because ports 0
through 5 are switched ports and ports 6 and 7 are PoE ports and both
require that you connect a straight through cable.
Connecting to Network Interfaces
Security
Services
Card Slot
4
3
2
1
0
1
2
2
Ethernet cable
ASA 5505 Getting Started Guide
Console
2
RESET
1
4-5
