Chapter 4
Installing the ASA 5505
6
7
8
*
78-18003-02
Port / LED
Color
Active
Green
Amber
VPN
Green
Amber
SSC
If the LINK/ACT LED does not light up, the link could be down if there is a duplex mismatch.
You can fix the problem by changing the settings either on the Cisco ASA 5505 or on the other
end. If auto-negotiation is disabled (it is enabled by default), you might be using the wrong type
of cable.
State
Description
Solid
The system is forwarding traffic.
If the system is part of a high
availability setup, a solid green
light indicates that the link is
forwarding traffic.
Solid
The system is on standby.
If the system is part of a high
availability setup, a solid amber
light indicates that this is the
standby unit.
Solid
The VPN tunnel is established.
Flashing The system is initiating the VPN
tunnel.
Solid
The tunnel failed to initiate.
An SSC card is present in the SSC
slot.
ASA 5505 Getting Started Guide
Ports and LEDs
4-11
