Ports and LEDs
Rear Panel Components
Port or LED
1
Power connector
2 Security service card slot
3 Serial console port
4
Lock device
5 RESET button
6
Two USB v2.0 ports
7 Ethernet switch ports 0–7
8 PoE switch ports 6–7
ASA 5505 Getting Started Guide
4-12
Figure 4-5 illustrates the back panel of the Cisco ASA 5505.
Figure 4-5 ASA 5505 Rear Panel
1 2
power
48 VDC
7
POWER over ETHERNET
8
Purpose
Attaching the power cord.
Reserved for future use.
Managing the device using the CLI (command-line interface).
Reserved for future use.
Reserved for future use.
Reserved for future use.
Layer 2 switch ports that provide flexible VLAN configuration.
Note Ethernet switch ports 6 and 7 also support PoE devices. If
a PoE device is not attached, power is not supplied to the
port and the device must be powered on its own.
Can be used for PoE devices, that is, devices that can be powered by
the network interface, such as IP phones.
These ports are the only ports that can be used for IP phones or other
PoE devices. However, these ports are not restricted to that use.
They can also be used as Ethernet switch ports, as are the ports
numbered 0 through 5. If a PoE device is not attached, power is not
supplied to the port and the device must be powered on its own.
Security
Services
Card Slot
6 5 4 3 2
7
Chapter 4 Installing the ASA 5505
3
Console
2
1
1 0
6
4
RESET
5
