TJERNLUND IN-LINE DRAFT INDUCER REFERENCE GUIDE 8500590 REV. B 0403 Reference Manual

Residential Commercial
Reference Guide
Improve Heating Efficiency
In-Line Draft Inducers assure positive draft
when restricted boilers and furnaces, poor
chimneys or negative pressures in build-
ings prevent proper exhaust of combus-
tion gases. The Venturi action starts air
moving up the stack instantly and keeps it
moving smoothly. In-Line inducers are
built for long-lasting, trouble-free service
and available in sizes and capacities to
meet virtually all heating system require-
ments. The Vari-Draft control permits
adjustment to individual job require-
ments. Vents/Chimneys utilizing In-Line
Draft Inducers must be vertically terminat-
ed above the roof line.
Use On Vertically Terminated Vent Systems Only
Industrial
www.tjernlund.com • 800.255.4208
In-Line
Draft
Inducers
by
Tjernlund
Typical Applications:
• Boilers/Furnaces
• Water Heaters
• Modular Boiler Systems
• Multiple Appliances
• Bakery Ovens
• Factory Processes
Solves Venting Problems:
• Undersized Chimneys
• Negative Pressures
• Long Horizontal Vent Connectors
• Down Drafts
• Cold Equipment Starts
• Restrictive Heat Exchangers/Combustion
Chambers
