EVM User's Guide: TPS922050/1EVM
TPS922051/0 65V 2A/1A Buck LED Driver Evaluation
Module with PWM/Analog Dimming
Description
The TPS922051/0 evaluation module (EVM) is a
two-layer PCB assembly with multiple variants to
help the user evaluate the main features and
performance of the TPS922051/0 device family. The
TPS922051/0 is a 2A / 1A non-synchronous Buck
LED driver with 4.5V to 65V wide input range with
PWM / analog dimming function. By integrating the
low-side NMOS, the device is capable of driving
LEDs with high power density and high efficiency.
This document includes setup guidance, schematics,
printed-circuit board (PCB) layouts, and bill of
materials (BOM) for the whole family of TPS922051/0
EVMs, including TPS922051D1DSGREVM,
TPS922051D2DSGREVM,
TPS922050D1DSGREVM,
TPS922050D2DSGREVM,
TPS922051D1DGNREVM,
TPS922051D2DGNREVM,
TPS922050D1DGNREVM,
TPS922050D2DGNREVM, TPS922050D1DRLREVM
and TPS922050D2DRLREVM.
Features
LED common anode connection
Integrated 300mΩ MOSFET
SLUUD71 – DECEMBER 2024
Submit Document Feedback
– Typical current limit (1.6A / 3.2A)
– Switching frequency (400kHz / 1MHz)
Advanced dimming options:
– D1 for PWM dimming
– D2 for Analog dimming
Full protection features:
– LED open and short protection
– Switching FET open and short protection
– External component failure protection
– Cycle-by-cycle current limit
– Thermal shutdown
Package: WSON-8, HVSSOP-8, SOT583
Applications
Constant illumination:
– Indoor and outdoor lighting
– Appliance lighting
– Cold/warm WLED lighting
– Emergency and signage lighting
– Security floodlight
– LED bulb and lamp
– LCD backlight
Instant illumination
– Machine vision and camera flash
– Fire alarm and strobe
Figure 1-1. TPS922051D1DSGREVM
TPS922051/0 65V 2A/1A Buck LED Driver Evaluation Module with PWM/
Copyright © 2024 Texas Instruments Incorporated
Description
1
Analog Dimming

Advertisement

loading
Need help?

Need help?

Do you have a question about the TPS922051/0 and is the answer not in the manual?

Questions and answers

Summary of Contents for Texas Instruments TPS922051/0

  • Page 1 – Machine vision and camera flash • Integrated 300mΩ MOSFET – Fire alarm and strobe Figure 1-1. TPS922051D1DSGREVM SLUUD71 – DECEMBER 2024 TPS922051/0 65V 2A/1A Buck LED Driver Evaluation Module with PWM/ Submit Document Feedback Analog Dimming Copyright © 2024 Texas Instruments Incorporated...
  • Page 2 Evaluation Module Overview www.ti.com 1 Evaluation Module Overview 1.1 Introduction The TPS922051/0 evaluation module (EVM) is designed for evaluating the device family of TPS922051/0 LED driver. Table 1-1 lists the available EVMs in the TPS922051/0 EVM family, the corresponding chip mounted on the PCB and its features.
  • Page 3 1.4 Device Information The TPS922051/0 is a 2A / 1A non-synchronous Buck LED driver with 4.5V to 65V wide input range and PWM / analog dimming function. By integrating the low-side NMOS, the device is capable of driving LEDs with high SLUUD71 –...
  • Page 4 The device adopts an adaptive off-time current mode control along with smart and accurate sampling to enable fast PWM dimming and achieve high dimming ratio. The TPS922051/0 also provides multiple systematic protections, including LED open and short, switching FET open and short, sense resistor open and short, and thermal shutdown.
  • Page 5 Limitation for Safe Use: – EVMs are not to be used as all or part of a production unit. SLUUD71 – DECEMBER 2024 TPS922051/0 65V 2A/1A Buck LED Driver Evaluation Module with PWM/ Submit Document Feedback Analog Dimming Copyright © 2024 Texas Instruments Incorporated...
  • Page 6 High Voltage! Electric shock is possible when connecting board to live wire. Board must be handled with care by a professional. For safety, use of isolated test equipment with overvoltage and overcurrent protection is highly recommended. TPS922051/0 65V 2A/1A Buck LED Driver Evaluation Module with PWM/ SLUUD71 – DECEMBER 2024 Analog Dimming Submit Document Feedback...
  • Page 7 Isolated DC Bench Power Supply Func o n Generator ¡ Figure 2-1. Connection Diagram of TPS922051D1DSGREVM SLUUD71 – DECEMBER 2024 TPS922051/0 65V 2A/1A Buck LED Driver Evaluation Module with PWM/ Submit Document Feedback Analog Dimming Copyright © 2024 Texas Instruments Incorporated...
  • Page 8 DIM_IN Test point to apply positive DIM input signal Negative power input test point (GND) GND test point TPS922051/0 65V 2A/1A Buck LED Driver Evaluation Module with PWM/ SLUUD71 – DECEMBER 2024 Analog Dimming Submit Document Feedback Copyright © 2024 Texas Instruments Incorporated...
  • Page 9 Blue: LED current Figure 3-1. LED current and SW waveform of TPS922051D1DSGREVM at DIM = 50%, 1kHz SLUUD71 – DECEMBER 2024 TPS922051/0 65V 2A/1A Buck LED Driver Evaluation Module with PWM/ Submit Document Feedback Analog Dimming Copyright © 2024 Texas Instruments Incorporated...
  • Page 10 1000pF VIN-IC 200k 1502-2 TP5 DIM_INPUT 100nF 1502-2 1502-2 Figure 4-1. Schematic of LED034, LED035 TPS922051/0 65V 2A/1A Buck LED Driver Evaluation Module with PWM/ SLUUD71 – DECEMBER 2024 Analog Dimming Submit Document Feedback Copyright © 2024 Texas Instruments Incorporated...
  • Page 11 10.0M 1000pF VIN-IC 200k 1502-2 TP5 DIM_INPUT 100nF 1502-2 1502-2 Figure 4-2. Schematic of LED036 SLUUD71 – DECEMBER 2024 TPS922051/0 65V 2A/1A Buck LED Driver Evaluation Module with PWM/ Submit Document Feedback Analog Dimming Copyright © 2024 Texas Instruments Incorporated...
  • Page 12 Figure 4-4. LED034 Bottom Layer 4.2.2 PCB Layout of LED035 (HVSSOP Package) The PCB layout of LED035 (HVSSOP package) is shown below. TPS922051/0 65V 2A/1A Buck LED Driver Evaluation Module with PWM/ SLUUD71 – DECEMBER 2024 Analog Dimming Submit Document Feedback...
  • Page 13 4.2.3 PCB Layout of LED036 (SOT583 Package) The PCB layout of LED036 (SOT583 package) is shown below. SLUUD71 – DECEMBER 2024 TPS922051/0 65V 2A/1A Buck LED Driver Evaluation Module with PWM/ Submit Document Feedback Analog Dimming Copyright © 2024 Texas Instruments Incorporated...
  • Page 14 Hardware Design Files www.ti.com Figure 4-7. LED036 Top Layer Figure 4-8. LED036 Bottom Layer TPS922051/0 65V 2A/1A Buck LED Driver Evaluation Module with PWM/ SLUUD71 – DECEMBER 2024 Analog Dimming Submit Document Feedback Copyright © 2024 Texas Instruments Incorporated...
  • Page 15 TPS922051/0 EVM variants. Table 4-2 lists the parts exclusive to different TPS922051/0 EVM variants. If the part shows 0 in Qty., it means that the part is not populated on the EVM. Table 4-1. Common Bill of Materials (BOM) for All TPS922051/0 EVM Variants Designator Qty.
  • Page 16 Hardware Design Files www.ti.com Table 4-1. Common Bill of Materials (BOM) for All TPS922051/0 EVM Variants (continued) Designator Qty. Description Part Number Manufacturer TP1, TP2, TP3, Terminal, Turret, TH, Double 1502-2 Keystone TP4, TP5, TP6, CAP, CERM, 0.1 uF, 100 V, +/-...
  • Page 17 Hardware Design Files Table 4-2. Exclusive Bill of Materials (BOM) for Different TPS922051/0 EVM Variants Designator Qty. Description Part Number Manufacturer EVM Variant 65V 2A Buck LED Driver TPS922051D1DSGR Texas Instruments TPS922051D1DSGREVM with PWM Dimming, WSON 65V 2A Buck LED Driver...
  • Page 18 Hardware Design Files www.ti.com Table 4-2. Exclusive Bill of Materials (BOM) for Different TPS922051/0 EVM Variants (continued) Designator Qty. Description Part Number Manufacturer EVM Variant 10µF ±10% 100V Ceramic GRM32EC72A106KE05L Murata All TPS922051 EVM, Capacitor X7S 1210 (3225 TPS922050D1DRLREVM, Metric) TPS922050D2DRLREVM 10µF ±10% 100V Ceramic...
  • Page 19 Compliance Information 5 Compliance Information 5.1 Compliance and Certifications • TPS922051D1DSGREVM EU Declaration of Conformity (DoC) SLUUD71 – DECEMBER 2024 TPS922051/0 65V 2A/1A Buck LED Driver Evaluation Module with PWM/ Submit Document Feedback Analog Dimming Copyright © 2024 Texas Instruments Incorporated...
  • Page 20 6 Additional Information 6.1 Trademarks All trademarks are the property of their respective owners. TPS922051/0 65V 2A/1A Buck LED Driver Evaluation Module with PWM/ SLUUD71 – DECEMBER 2024 Analog Dimming Submit Document Feedback Copyright © 2024 Texas Instruments Incorporated...
  • Page 21 Related Documentation 7 Related Documentation • TPS922050/1 65V 1A/2A Buck LED Driver with PWM/Analog Dimming datasheet SLUUD71 – DECEMBER 2024 TPS922051/0 65V 2A/1A Buck LED Driver Evaluation Module with PWM/ Submit Document Feedback Analog Dimming Copyright © 2024 Texas Instruments Incorporated...
