TPS65251 Buck Converter Evaluation Module User's
Guide
1
Introduction.............................................................................................................................................................................2
2
Background.............................................................................................................................................................................3
3
Schematic................................................................................................................................................................................4
Layer)............................................................................................................................................................6
5 Bench Test Setup Conditions................................................................................................................................................
5.2
Jumpers..............................................................................................................................................................................8
Placement.................................................................................................................................................8
6 Power-Up Procedure..............................................................................................................................................................
7 Bill of Materials.....................................................................................................................................................................
History....................................................................................................................................................................11
Trademarks
All trademarks are the property of their respective owners.
SLVU399B - AUGUST 2010 - REVISED MAY 2021
Submit Document Feedback

Table of Contents

Placement.....................................................................................................................7
Copyright © 2021 Texas Instruments Incorporated
TPS65251 Buck Converter Evaluation Module User's Guide
Table of Contents
7
9
10
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPS65251 and is the answer not in the manual?

Questions and answers

Summary of Contents for Texas Instruments TPS65251

  • Page 1: Table Of Contents

    7 Bill of Materials..................................8 Revision History..................................11 Trademarks All trademarks are the property of their respective owners. SLVU399B – AUGUST 2010 – REVISED MAY 2021 TPS65251 Buck Converter Evaluation Module User's Guide Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 2: Introduction

    Introduction www.ti.com 1 Introduction This document presents the information required to power the TPS65251 PMIC as well as the support documentation including schematic and bill of materials. TPS65251 Buck Converter Evaluation Module User's Guide SLVU399B – AUGUST 2010 – REVISED MAY 2021 Submit Document Feedback Copyright ©...
  • Page 3: Background

    2 Background The TPS65251 PMIC is designed to provide 3-A and 2-A continuous outputs with an operational range of 4.5 V to 18 V and an externally set switching frequency ranging from 300 kHz to 2.2 MHz. When the PMIC is not fully loaded, Buck1 can be loaded to 3.5 A and Buck2 and Buck3 to 2.5 A.
  • Page 4: Schematic

    3 Schematic See next page. The resistor and capacitor values have been chosen according to the guidelines presented on the TPS65251 spec available at http://focus.ti.com/docs/prod/folders/print/tps65251.html. Note that for the purpose of gains-phase measurements R10, R19 and R21 (0 Ω on the EVM) need to be replaced by suitable low value resistors as per the network analyzer setup required.
  • Page 5 Schematic Figure 3-1. TPS65251 Schematic SLVU399B – AUGUST 2010 – REVISED MAY 2021 TPS65251 Buck Converter Evaluation Module User's Guide Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 6: Placement (Top Layer)

    Placement (Top Layer) www.ti.com 4 Placement (Top Layer) Figure 4-1. Placement (Top Layer) TPS65251 Buck Converter Evaluation Module User's Guide SLVU399B – AUGUST 2010 – REVISED MAY 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 7: Bench Test Setup Conditions

    Black – GND White – Each output, feed-back, power good and V . All marking on PCB. SLVU399B – AUGUST 2010 – REVISED MAY 2021 TPS65251 Buck Converter Evaluation Module User's Guide Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 8: Jumpers

    TP28 V7V pin (internal rail) White TP29 V3V pin (internal rail) White TP33 Input supply White TPS65251 Buck Converter Evaluation Module User's Guide SLVU399B – AUGUST 2010 – REVISED MAY 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 9: Power-Up Procedure

    5. For low power and SYNC operation remove the jumpers and connect control supplies as indicated in the bench test setup section. SLVU399B – AUGUST 2010 – REVISED MAY 2021 TPS65251 Buck Converter Evaluation Module User's Guide Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 10: Bill Of Materials

    0603 SMD RES 287 kΩ 287 kΩ Panasonic -ECG ERJ-3EKF2873V 1/10 W 1% Resistor 0603 SMD TPS65251 Buck Converter Evaluation Module User's Guide SLVU399B – AUGUST 2010 – REVISED MAY 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
  • Page 11: Revision History

    Updated user's guide title........................... • Updated the numbering format for tables, figures, and cross-references throughout the document....2 SLVU399B – AUGUST 2010 – REVISED MAY 2021 TPS65251 Buck Converter Evaluation Module User's Guide Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated...
