Installation Guide
For Model:
OMCY52-PC
*PLEASE NOTE:
Parts drawings in
this manual are
representative only
APPROVED FOR USE
IN WET LOCATIONS
4007498
net weight of fan: 17.2 lb (7.8 kg)
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE
Table of Contents:
Safety Tips. pg. 2
Unpacking Your Fan. pg. 3
Parts Inventory. pg. 3
Installation Preparation. pg. 4
Hanging Bracket Installation. pg. 4
Fan Assembly. pgs. 5 - 6
Wiring. pg. 6
Canopy Assembly. pg. 7
Blade Assembly. pg. 7
Light Kit Assembly (Optional). pg. 8
Testing Your Fan. pg. 9
Troubleshooting. pg. 10
Warranty. pg. 10
Parts Replacement. pg. 10
page 1
PRINTED IN CHINA
Advertisement
Related Manuals for Craftmade OMCY52-PC
Summary of Contents for Craftmade OMCY52-PC
- Page 1 READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Installation Guide For Model: OMCY52-PC Table of Contents: Safety Tips. pg. 2 Unpacking Your Fan. pg. 3 Parts Inventory. pg. 3 Installation Preparation. pg. 4 *PLEASE NOTE: Hanging Bracket Installation. pg. 4 Parts drawings in Fan Assembly.
- Page 2 LOW speed.] Do not use detergents when cleaning the fan or fan blades. A dry dust cloth or lightly dampened cloth will be suitable for most cleaning. Distributed by: Craftmade, 3901 S. 20 Avenue, DFW Airport, TX, 75261; 800-486-4892 NOTE: The important safety precautions and instructions appearing in the manual are not meant to cover all possible conditions and situations that may occur.
- Page 3 1. Unpacking Your Fan. Carefully open the packaging. Remove items from packing material. Remove motor housing and place on carpet or packing material to avoid damage to finish. Do not discard fan carton or packing material should this fan need to be returned for repairs.
- Page 4 3. Installation Preparation. To prevent personal injury and damage, ensure that blade edge the hanging location allows the blades a clearance of (30) 7 feet (2.13m) from the floor and 30in. (76cm) from inches any wall or obstruction. (76cm) 7 feet The fan is suitable for room sizes up to 400 square (2.13m) feet (37.2 square meters).
- Page 5 stop pin 5. Fan Assembly. set screw Remove hanging ball from downrod provided by hanging ball loosening set screw on hanging ball. Remove pin and clip. Lower hanging ball and remove stop pin. Slide clip hanging ball off of the downrod. [Refer to diagram 1.] diagram 1 Loosen yoke set screws and nut at top of motor housing.
- Page 6 5. Fan Assembly. (cont.) safety cable loop wood With the hanging bracket secured to the outlet box and ceiling able to support the fan, you are now ready to hang your joist fan. Grab the fan firmly with two hands. Slide downrod through opening in hanging bracket and let hanging wood screw ball rest on the hanging bracket.
- Page 7 7. Canopy Assembly. hanging bracket Partially loosen the 2 screws on underside of hanging bracket. Lift canopy to hanging bracket. Align the rounded part of each slotted hole in screw center of canopy with the corresponding screw loosened screws in hanging bracket and push up. Twist canopy to lock and then tighten both screws securely.
- Page 8 motor motor 9. Light Kit Assembly. housing plate Remove 1 screw from motor plate on underside of motor housing and partially loosen the other 2 screws. Align slotted holes in center of switch housing plate with loosened screws in motor switch plate, allowing molex connections from motor housing...
- Page 9 10. Testing Your Fan. It is recommended that you test fan before finalizing installation. Restore power from circuit box and light switch (if applicable). Test fan speeds with the pull chain located to the left of switch housing reverse the reverse switch. Start at the OFF position (no plate switch blade movement).
- Page 10 WARNING: Failure to disconnect power supply CRAFTMADE LIMITED LIFETIME WARRANTY: prior to troubleshooting any wiring issues may CRAFTMADE warrants this fan for use as intended under the following provision: CRAFTMADE will result in serious injury. replace any fan which has faulty performance due to a defect in material or workmanship or fails to operate Problem: Fan fails to operate.
