Quick Guide
Industrial Mainboard
GMB-IRPLx00
CONTENTS
Introduction .................................................................. 4
Safety Precautions .................................................... 10
Product Nomenclature and Function ............... 16
BIOS Setup .................................................................. 40
Appendix ...................................................................... 69
List of Optional Products ....................................... 82
Customer Support and Inquiry ............................ 84
Advertisement
Related Manuals for Contec GMB-IRPL 00 Series
Summary of Contents for Contec GMB-IRPL 00 Series
- Page 1 Quick Guide Industrial Mainboard GMB-IRPLx00 CONTENTS Introduction ..............4 Safety Precautions ............ 10 Product Nomenclature and Function ....16 BIOS Setup ..............40 Appendix ..............69 List of Optional Products ........82 Customer Support and Inquiry ......84...
- Page 2 Product Nomenclature and Function This section describes product component names and their functions, pin assignment of each connector. - 16 -...
- Page 3 Product Nomenclature and Function GMB-IRPLX00 Reference Manual 1. Product Overview connectors of the product are shown in the picture below. Top View - 17 -...
- Page 4 Product Nomenclature and Function GMB-IRPLX00 Reference Manual 2. Jumper List For users to customize GMB-IRPLX00 features. In the following sections, short means covering a jumper cap over jumper pins; Open or N/C (not connected) means removing a jumper cap from jumper pins.
- Page 5 Product Nomenclature and Function GMB-IRPLX00 Reference Manual 3 Connector List - 19 -...
- Page 6 Product Nomenclature and Function GMB-IRPLX00 Reference Manual Ref. Connector Function AUDIO 1 Audio Jack (Line-out,Line-in,MIC-in) / (LOTES: ABA-JAK-027-K21) LANUSB 3 RJ45 + USB3.1 Gen2 Connector ( Onboard LAN C ) LANUSB 2 RJ45 + USB3.1 Gen2 Connector ( Onboard LAN B ) LANUSB 1 RJ45 + USB2.0 Connector ( Onboard LAN A ) USB 1...
- Page 7 Product Nomenclature and Function GMB-IRPLX00 Reference Manual 1. DC-IN Power Connector 4P :(POW1,POW2) POW1 POW2 PIN No. Signal Description 12/19/24V 12/19-24V 2. Front Panel Pin HDR :(F_PANEL_1) Pitch:2.00mm PIN No. Signal Description PIN No. Signal Description HDDLED(+) PWRLED(+) HDDLED(-) PWRLED(-) PWRSW RSTSW - 21 -...
- Page 8 Product Nomenclature and Function GMB-IRPLX00 Reference Manual 3. CPU FAN Connector :(CPU_FAN_1) PIN No. Signal Description +12V Sense Control 4. System FAN Connector :(SYS_FAN_1) PIN No. Signal Description 1 2 3 4 +12V Sense Control - 22 -...
- Page 9 Product Nomenclature and Function GMB-IRPLX00 Reference Manual 5. SPI connector 9P: (SPI_1) PIN No. Signal Description PIN No. Signal Description 3.3V_SPI SPIROM_SO SPIROM_CLK SPIROM_SO3 SPIROM_CS# SPIROM_S1 SPIROM_SO2 6. Front Panel Audio Connector (F_AUDIO_1) PIN No. Signal Description PIN No. Signal Description B_LINE2-JD LINE2-L _ AGND...
- Page 10 Product Nomenclature and Function GMB-IRPLX00 Reference Manual 7. 8-bit GPIO Pin header (GPIO_1) Pitch:2.00mm PIN No. Signal Description PIN No. Signal Description DIO_GP1 DIO_GP2 DIO_GP3 DIO_GP4 DIO_GP5 DIO_GP6 DIO_GP7 DIO_GP8 5V_SB 8. SATA 3.0 Connector : (SATA1,SATA2) SATA 1 SATA 2 PIN No.
- Page 11 Product Nomenclature and Function GMB-IRPLX00 Reference Manual M.2 M Key Socket :(M2_1) Bottom side M.2 M Key Socket (PCIe x4 Signal)/ H=4.2mm The board has one mechanical connector key M, accepting type 2242 of M.2 modules M.2 Key E Socket :(M2_2) M.2 E Key Socket (PCIe + USB 2.0 Signal) H=8.5mm The board has one mechanical connector key E, accepting type 1630 or 2230 of M.2 modules - 25 -...
- Page 12 Product Nomenclature and Function GMB-IRPLX00 Reference Manual 11. RS232/422/485 Port :(COM1,COM2,COM3) COM1~COM3 (Box header). Pitch: 2.0mm Signal Description RS-422 RS-485 PIN No. RS-232C Full Duplex Half Duplex RTS- RTS+ CTS+ CTS- 12. Battery Connector 2P :(BATTER 2) PIN No. Signal Description PIN No.
- Page 13 Product Nomenclature and Function GMB-IRPLX00 Reference Manual 13. Audio Jack :(AUDIO 1) 14. HDMI Connector :(HDMI 1) PIN No. Signal Description PIN No. Signal Description HDMI1 DATA2(+) HDMI1 DATA2(-) HDMI1 DATA1(+) HDMI1 DATA1(-) HDMI1 DATA0(+) HDMI1 DATA0(-) HDMI1 CLK(+) HDMI1 CLK(-) HDMI1 DDC_SCL HDMI1 DDC_SDA HDMI1_5V...
- Page 14 Product Nomenclature and Function GMB-IRPLX00 Reference Manual 15. M.2 key B Socket :(M2_3) M.2 Key B Socket (PCIe x2 +USB2.0 Signal) H=4.2mm The board has one mechanical connector key B, accepting type 3042 or 3052 of M.2 modules 16. Nano SIM Socket (CN4) PIN No.
- Page 15 Product Nomenclature and Function GMB-IRPLX00 Reference Manual CAUTION [ Figure-B ] [ Figure-A ] 1) Slide the socket lid (Unlock ) as Figure-A 2) Open the socket lid, place the card into the socket 3) Closed socket lid as Figure-B 4) Slide the socket lid lock for safely 17.
- Page 16 Product Nomenclature and Function GMB-IRPLX00 Reference Manual Lane0- Lane1+ Lane1- Lane2+ Lane2- Lane3+ Lane3- Aux+ Aux- HotPlug 3.3V CAUTION The display may not be viewed if you start the BIOS setup menu without connecting the display cable to the DisplayPort interface, then connect the display cable after booting.
- Page 17 Product Nomenclature and Function GMB-IRPLX00 Reference Manual VDS_A_TXL+2_C EDP1_VDD_EN EDP1_BKLT_EN LVDS_A_TXL-1_C EDP_HPD_R LVDS_A_TXL+1_C GND N LVDS_A_TXL-0_C LVDS_A_TXL+0_C EDP_12V EDP_12V LVDS_A_TXL-3_C EDP_12V LVDS_A_TXL+3_C EDP_12V 19. RJ45+USB3.1 Gen2 Connector (LANUSB 2/ LANUSB 3) LANUSB 3 LANUSB 2 RJ45 Port LED Indications : RJ45 LEDs for display of network status: Speed LED Speed LED...
- Page 18 Product Nomenclature and Function GMB-IRPLX00 Reference Manual Activity LED State Description No data or receiving is occurring Blinking Data transmission or receiving is occurring Green Link UP PIN No. Signal Description TX1+ TX1- TX2+ TX3+ TX3- TX2- TX4+ TX4- PIN No. Signal Description PIN No.
- Page 19 Product Nomenclature and Function GMB-IRPLX00 Reference Manual RJ45 Port LED Indications : RJ45 LEDs for display of network status: Speed LED Speed LED Activity LED State Description No Link Green 10/100 Mbps data rate Orange 1 Gbps data rate Activity LED State Description No data or receiving is occurring...
- Page 20 Appendix This section lists the specifications and components suggestion, block diagram, driver installation, and mechanical drawing. - 65 -...
- Page 21 Appendix GMB-IRPLX00 Reference Manual 1. System Reference 1. Specifications Model Name GMB-IRPLX00 Intel®13th Generation Core™i3/ i5/ i7 Processors (LGA1200) up to 28W TDP BIOS AMI UEFI BIOS Operation System Windows®10 IoT Enterprise LTSC 2021 64 bit System Memory 2 x DDR5SO-DIMM socket, up to 32GB Storage 2 x SATA III (6.0Gb/s) Port Controller: Intel®...
- Page 22 Appendix GMB-IRPLX00 Reference Manual 2. Block Diagram - 67 -...
