CAME AXO-S524 KIT Quick Setup Manual

CAME AXO-S524 KIT Quick Setup Manual

Complete kit for a single swing gate weighing up to 400kg / max. width 5m, zlx24 panel version
Hide thumbs

Advertisement

Quick Links

Download this manual
CAME.COM/UK
AXO-S524
kit
Complete kit for a single swing gate weighing
up to 400kg / max. width 5m
ZLX24
PANEL
VERSION
QUICK SETUP GUIDE
Typical gate setup & geometry
Gate motor manual release
Kit wiring diagram
Control panel guide & safety
TO BE READ IN CONJUNCTION WITH THE FULL INSTRUCTION MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the AXO-S524 KIT and is the answer not in the manual?

Questions and answers

Related Manuals for CAME AXO-S524 KIT

Summary of Contents for CAME AXO-S524 KIT

  • Page 1 CAME.COM/UK AXO-S524 Complete kit for a single swing gate weighing up to 400kg / max. width 5m ZLX24 PANEL VERSION QUICK SETUP GUIDE Typical gate setup & geometry Gate motor manual release Kit wiring diagram Control panel guide & safety...
  • Page 2 CONTENTS Kit Contents Initial Power On Safety Instructions Commissioning the RGSM Typical Gate Setup Commissioning via App Geometry Commissioning via Panel Manual Release Instructions Safety Options Wiring Diagram Replacing the SIM Card Pre-installed SIM Card Optional Accessories AXO-S524: KIT CONTENTS AX5024 ZLX24SA AF43S...
  • Page 3 SAFETY INSTRUCTIONS When correctly installed in compliance to installation instructions and adhering to all current electrical, mechanical and manufacturer regulations, your automation system will provide a high degree of safety and problem free operation. Please take note of the following warnings that must be followed in order to prevent accidents during your gate operation: •...
  • Page 4 TYPICAL GATE SETUP OUTSIDE OF GATES INSIDE OF GATES AXO Motor Flashing Light (optional) 2nd set of Photocells (optional) Control Panel Selector Keypad (optional) Mechanical End Stop (not supplied) Reception Antenna Photocells (on outside of gate posts) Photocell column (optional accessory) CONTROL PANEL •...
  • Page 5 GEOMETRY Preliminary checks Tick 1. Check that the gate structure is sturdy enough, the hinges work efficiently and that there is no friction between the fixed and moving parts 2. Make sure that measurement does not exceed the value shown in the reference table 3.
  • Page 6 MANUAL RELEASE The AXO worm drive swing gate operators have a manual release lock beneath a hatch on the top of the motors. To manually release the gates: 1. Slide open the hatch covering the lock 2. Insert key into lock and turn until it clicks 3.
  • Page 7 wiring diagram Mains Supply ZLX24SA 230 V AC Control Panel Cable/length 1m - 20m = 3 Core 1.5mm 20m - 30m = 3 Core 2.5mm 10 2 TX C NC TX 2 Photocells Cable/length RX 4 Core 0.5mm Flex TX 4 Core 0.5mm Flex 1m - 30m Set RSE jumper to OFF...
  • Page 8 Approx. 5+ gate manoeuvres per 1-3 Years day, multiple scenarios running Due to situations outside of our control, CAME cannot guarantee signal strength or availability and therefore will not be held liable for lack of service. setup app for the installer...
  • Page 9 TITLE initial power ON Power on the control board. The display will read Keycode 123456789ABCDE F Installer Tip MATR If the RGSM001S is located 54051 6 in a concealed area and a low RGSM001S GSM signal observed a 2m extension cable and bracket is 300mAE GSM –...
  • Page 10 Mr Wilson, Sills Road, DE74 2US Mr Wilson, Sills Road, DE74 2US 3.1 Open the App and log in 3.2 Select “CAME Connect 3.3 Select “Installations 3.4 Select “New Installation”. using your technician details connection”.
  • Page 11 TITLE commissioning the rgsm Installer Tip The Name and Description entered here, can be used to identify the site location. Name: Mr Wilson, Sills Rd, DE74 2US Description: Mr Wilson, Sills Rd, DE74 2US This shows in the Installers Setup App, under the site management list.
  • Page 12 TITLE COMMISSIONING VIA APP adding automation AXO - ZLX24S - Automation for swing gates Front Gates Front Gates Installer Tip The Name and Description entered here, can be used to identify the gate location Name: Front Gates Description: Front Gates This shows under the customers Automation App on the main display...
  • Page 13 TITLE COMMISSIONING VIA APP Set the safety inputs (please Select Calibrating Travel. When the gate has successfully refer to section 12 for calibrated, it will automatically options). Select Next. display the dialog box shown below. Select Yes. Once it has been accepted on Select Add.
  • Page 14 COMMISSIONING VIA APP Once it has been accepted on Select the back button to If you select ADD via QR Once the QR code has been the control panel It will display return to the main menu. Code, the app will open the scanned, enter a Name and the above screen.
  • Page 15 TITLE COMMISSIONING VIA APP transfer to customer name@mycustomer.co.uk name@mycustomer.co.uk Firstname Lastname To transfer to a customer, Select Transfer site Enter customer details you Select confi rm. The customer select the 3 dots. wish to transfer to. will get an email asking to confi rm the account.
  • Page 16 Safety inputs should now be configured and the gate force tested as required. Please refer to the full manual to complete the commissioning. Should the gates not operate as suggested above, call CAME helpline 0115 921 0430 for technical support.
  • Page 17 User management – Radio coding Select the type of Radio-frequency coding. All decoding - Rolling code - TW key block Confi rm - YES Should the transmitter not operate as suggested above, call CAME helpline 0115 921 0430 for technical support.
  • Page 18 TITLE SAFETY options SAFETY INPUTS FUNCTIONS > CX Input, CY Input, CZ Input, CK Input REOPENING DURING CLOSING • When the automation is in its closing cycle and the safety circuit is triggered the automation will stop and reverse its motion until it reaches its fully open position again.
  • Page 19 SAFETY options SENSITIVE EDGES FUNCTIONS > CX Input, CY Input, CZ Input, CK Input REOPENING DURING CLOSING • When the automation is in its closing cycle and the safety circuit is triggered the automation will reverse its motion until it reaches its fully open position again.
  • Page 20 APN details e.g. APN:pp.vodafone.co.uk Capital, lowercase letters and punctuation must be respected The SIM must be capable of 2G data transmission and have the PIN code disabled. Full instructions for the RGSM001S module can be found be visiting: https://docs.came.com/pdf/FA01289M4A.pdf...
  • Page 21 Natural-finish anodised aluminium post for bi-directional fitting. H = 500 mm 001DELTA-BN Black anodised aluminium post for bi-directional fitting. H = 500 mm CAME KEY 806SA-0110 WiFi internet gateway. Communicate directly with your smartphone or tablet, allowing you to manage the configuration of your device with no need for an internet connection.
  • Page 22 User to submit a contractual offer, which will be submitted by password. fi lling in the Form. Came reserves the right to accept or reject said offer. Except in the event that a third party violates the Came computer systems, the User shall be exclusively responsible for maintaining the 4.3 The Contract will be considered concluded at the moment in which the...
  • Page 23 Italy, by the Italian conditions, Came will not be in any way liable for the failed or faulty Legislative Decree dated 6 September 2005, no. 206, “Consumer provision of the Service, nor will it be liable for any loss, damage or Code”, with specifi...
  • Page 24 Court of Treviso (Italy). CAMECONNECT 8.3 Came reserves the right to make changes to the Terms of Use at any 3.1 CameConnect has the features described in detail in the User Manual. time, publicising them on this page. In the event of a failure to accept the changes made to the Terms of Use, the Installer may withdraw 3.2 The features of the Software and CameConnect are subject to change...
  • Page 25 TITLE TITLE terms and conditions General Terms and Conditions of 1NCE GmbH for M2M/IoT mobile communications services (version as of 07/2018) 3.1 lit. c) of these GTC. 1NCE expressly points out that the type and Scope of application scope of such services of the respective mobile network operators, 1.1 The following General Terms and Conditions (hereinafter referred to as in particular also the respective available transmission technologies “GTC”) shall govern any and all contracts relating to the provision of...
  • Page 26 TITLE terms and conditions of receipt of the relevant Chip Cards by the Customer. Liability for Section 3.3 sentence 2 of these GTC shall be determined by the price damages due to defects is limited in accordance with the provisions of list of 1NCE valid at the time of this purchase.
  • Page 27 TITLE terms and conditions 10.2 The Parties also undertake to treat all other confi dential information Liability of the other Party that the receiving Party becomes aware of in Any liability of 1NCE for damages and/or reimbursement of expenses connection with the contractual relationship as strictly confi dential arising from or in connection with the contractual relationship between and not to disclose such information to any third party for an unlimited 1NCE and the Customer shall be subject to the following limitations:...
  • Page 28 YOU MAY NOT EVEN PARTIALLY REPRODUCE THIS DOCUMENT CAME RESERVES THE RIGHT TO MAKE ANY CHANGES TO THIS DOCUMENT AT ANY TIME THE DATA AND INFORMATION SHOWN IN THIS CATALOGUE ARE SUBJECT TO CHANGE WITHOUT OBLIGATION TO GIVE PRIOR NOTICE BY CAME S.P.A, E&OE CAME S.p.A.
