- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Instrucciones de instalación Istruzioni di installazione Installationsanleitung Installatie-instructies Instruções de Instalação Instructions d´installation Large Flat Panel Static Wall Mount Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description PSMH2582...
- Page 2 2,000lbs (907.185kg). Reinforce Chief® is a registered trademark of Milestone AV Technologies. the structure as required before installing the component. All rights reserved.
- Page 3 Installation Instructions PSMH2582 LEGEND Tighten Fastener Pencil Mark Apretar elemento de fijación Marcar con lápiz Befestigungsteil festziehen Stiftmarkierung Apertar fixador Marcar com lápis Serrare il fissaggio Segno a matita Bevestiging vastdraaien Potloodmerkteken Serrez les fixations Marquage au crayon Loosen Fastener Drill Hole Aflojar elemento de fijación...
- Page 4 PSMH2582 Installation Instructions ASSEMBLY AND INSTALLATION distance from upper horizontal bracket. (See Figure 2) Mark the location of mounting holes for the lower horizontal Mount Installation bracket in base onto surface. (See Figure 2) Attach locking flags (G) to two of four vertical brackets (A) Drill eight 1/4"...
- Page 5 Installation Instructions PSMH2582 (B) x 2 (A) x 4 (F) x 32 Figure 4 10. Attach four vertical brackets (A) to two horizontal brackets (B) using remaining thirty-two M8 nylon lock nuts (F). The vertical brackets with locking flags installed must be attached as the outer two brackets.
- Page 6 PSMH2582 Installation Instructions (E) x 8 (D) x 8 Figure 6 Install eight mounting buttons (E) onto display using eight Move display forward until recessed area of mounting M8 x 35mm button head cap screws (D). (See Figure 6) buttons is positioned over lower area of teardrop mounting holes.
- Page 7 Installation Instructions PSMH2582...
- Page 8 F 877.894.6918 / 952.894.6918 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands P +31 (0)40 2668620 Chief Manufacturing, a products division F +31 (0)40 2668615 of Milestone AV Technologies Asia Pacific A Room 24F, Block D, Lily YinDu International Building LuoGang, BuJi Town, Shenzhen, CHINA.
