Convision CC-87 Series User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Benutzerhandbuch
CONVISION
CC-87xx Serie
Stand: April 2012
Convision Systems GmbH
www.convision.com
Installationshandbuch
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the CC-87 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Convision CC-87 Series

Summary of Contents for Convision CC-87 Series

  • Page 1 Benutzerhandbuch CONVISION CC-87xx Serie Stand: April 2012 Convision Systems GmbH www.convision.com Installationshandbuch...
  • Page 2 Im Installationshandbuch-Teil finden Sie die elektrische und mechanische Installation von der Kamera 2. Konfigurationshandbuch Im Konfigurations-Handbuchteil finden Sie die Beschreibung der Benutzerschnittstelle über den Internet-Browser und die Einstellungen der Parameter der Kamera, wie z.B. Videoeigenschaften, Ereignisse, usw. Benutzerhandbuch Convision Systems GmbH...
  • Page 3 Teil 1 Installationshandbuch Megapixel-Netzwerkkamera CONVISION CC-87xx Serie Stand: Januar 2012 Convision Systems GmbH...
  • Page 4 Warnung vor gefährlicher elektrischer Spannung. Zur Wartung befolgen Sie bitte die Anweisungen des Handbuches. INFORMATION - Dieses Gerät entspricht den Richtlinien der Kategorie A für digitale Geräte, gemäß § Teil 15 der FCC- Richtlinien und der CE-Richtlinien. Diese Richtlinien dienen dem angemessenen Schutz gegen schädliche Störung wenn das Gerät in einer kommerziellen Umgebung genutzt wird.
  • Page 5 Warnung Die Kamera muss regelmäßig gewartet werden. Kontaktieren Sie bitte einen Spezialisten für die Inspektion. Benutzen Sie bitte Ihre Kamera bei einem Defekt nicht weiter Falls Sie Ihre Kamera bei Rauchentwicklung oder Überhitzung weiterbenutzen, kann ein Brand verursacht werden. Installieren Sie die Kamera nur auf einem tragfähigen Untergrund Bei nicht passendem Untergrund kann es zu Verletzungen oder Beschädigungen kommen.
  • Page 6 Inhaltsverzeichnis Installation von IP-Scan auf einem Windows PC ....................4 Basis-Installation der Kamera ..........................4 Konfiguration der Netzwerk Einstellungen ......................6 Zugriff auf die IP-Kamera über das Web-Interface....................6 Wiederherstellung der Werkseinstellungen......................7 Installationshandbuch CC-87xx Serie...
  • Page 7 Das IP-Scan Programm dient zur Konfiguration von Netzwerkeinstellungen der Kamera. Das IP-Scan Programm steht Ihnen auf CD-ROM zur Verfügung oder Sie können es von unserer Website downloaden unter www.convision.de Basis-Installation der Kamera Bitte lesen Sie die folgenden Hinweise sorgfältig durch, bevor Sie mit der Installation beginnen. Die nachfolgenden Schritte sind empfohlene Arbeitsschritte zur Installation, es kann aber abhängig von der Installationsumgebung falls...
  • Page 8 Verbinden Sie das Netzwerk- und die Audio-Kabel. Der Stromanschluss kann direkt an den Power Terminal-Block (12V DC) oder über den DC Power Adapter der Kamera erfolgen. Wenn Sie den Power Adapter nutzen wollen, dann schließen Sie bitte den Adapter-Stecker (siehe unten) an den Power Terminal-Block ACHTUNG: Vergewissern Sie sich, das positive &...
  • Page 9 Konfiguration der Netzwerk Einstellungen Die Werkseinstellung der IP-Adresse lautet wie folgt: IP Address 192.168.1.2 Subnet Mask 255.255.255.0 Gateway 192.168.1.1 Starten Sie das IP-Scan Programm von der beigefügten CD-ROM und wählen Sie aus den angezeigten Geräten das Gerät mit der IP-Adresse 192.168.1.2, um die von Ihnen installierte Kamera zu konfigurieren. Wählen Sie dann die Taste „Change Settings“, um die Netzwerkeinstellungen Ihrer Kamera zu ändern.
  • Page 10 Wiederholen Sie die oben genannten Schritte bis alle ActiveX Controls initiert wurden. Sobald dieser Prozess vollständig abgeschlossen ist, wird das Live Bild im IE dargestellt. Wiederherstellung der Werkseinstellungen Es gibt zwei Methoden, die Werkseinstellungen wieder herzustellen. 1. Versorgen Sie die Kamera mit Strom, drücken und halten Sie die Reset Taste für 6 Sekunden lang gedrückt. Die Kamera wird dadurch automatisch auf die Werkseinstellungen zurückgesetzt.
  • Page 11 Teil 2 CONVISION CC-8xxx Cameras Users Manual Firmware Version 1.0.8 Stand: December 2011 Convision Systems GmbH...
  • Page 12 About This Guide The User’s Manual provides functionality and instructions for the 1080p/5M series. Before Using the IP Camera/Video Server  Check the PC requirements  Review the OS platform requirements  Read an special and import precautionary information  Having basic knowledge of network setup and configuration will be helpful...
  • Page 13 Contents INTRODUCTION 0 The live view Setup..............................2 Set the Snapshot/Recording Path ......................3 Controls and Status..........................3 Digital Zoom............................3 Information ............................4 Streaming............................4 Audio..............................4 Control (PTZ Control).......................... 5 setup System – Information .......................... 7 System – Generic Setting ........................7 Camera Name ............................
  • Page 14 RTSP URL ............................27 Administrator User & Password ......................28 Firefox...
  • Page 15 1 INTRODUCTION This guide is for the use with the 1080p/5MP series using firmware version 1.0.8.
  • Page 16 After logging into the IP camera via the browser, the user is first presented with the Live View interface. Below is an example of the Live View page. Following the screenshot is a discussion of the different areas within the Live View page. CONVISION CC-8*** Cameras User Manual...
  • Page 17 The right hand panel (Information, Streaming, Audio, Control) can be hidden by clicking the small arrow bordering the video and Streaming pane. Click the arrow (highlighted in green) to hide/display the right side panel. 1.1 Setup In the top right corner of the screen are three links. CONVISION CC-8*** Cameras User Manual...
  • Page 18 Motion Detection Alert will display when motion detection has been triggered. 1.3 Digital Zoom The Digital Zoom feature allows zooming in on a specific area. When using the View Size controls, a magnifying glass icon will replace the mouse pointer icon. CONVISION CC-8*** Cameras User Manual...
  • Page 19 The number of ROI which are enabled in the Video Setting – Profile Setting will determine the number of streams available for viewing. See the “Video Control – Video Setting” section for more information. 1.6 Audio Audio volume controls for speaker and microphone. Clicking on the icon will mute or enable. CONVISION CC-8*** Cameras User Manual...
  • Page 20 1.7 Control (PTZ Control) The PTZ control panel will not be present in those models where PTZ will not be used . Use the Set button to mark a preset, and the Go button to use a preset. CONVISION CC-8*** Cameras User Manual...
  • Page 21 The left hand panel lists the configuration nodes which can be viewed and modified. Clicking on an item will reveal sub menus which are available. To return to the Live View page, click the Live View link in the right hand corner. CONVISION CC-8*** Cameras User Manual...
  • Page 22 The Information page is always the initial page displayed when switching to the Setup view. Basic information related to the IP camera is displayed here. The page only displays information; no changes can be made here. 2.2 System – Generic Setting Camera Name CONVISION CC-8*** Cameras User Manual...
  • Page 23 This defines the method by which the digital in sensor operates. If the normal condition is open (N.O.), then the alarm will be triggered when the circuit is closed. The opposite applies for N.C. The camera LED lights can be enabled or disabled. CONVISION CC-8*** Cameras User Manual...
  • Page 24 Currently English, Simplified Chinese and Czech are available. 2.3 System – User Account Management User accounts can be added, edited or deleted via the controls in the left corner. Users are assigned to a group (admin, operator or viewer). CONVISION CC-8*** Cameras User Manual...
  • Page 25 IP and User Account settings can be preserved by checking the appropriate boxes. After selecting the new firmware file, click Update to proceed. Messages that the camera is upgrading and rebooting will follow during the upgrade. CONVISION CC-8*** Cameras User Manual...
  • Page 26 After upgrading, the ActiveX controls and IE cache & history should be cleared to prevent old pages and controls from being used. Close all instances of IE and open 1 IE window. In the right corner, select Tools->Manage Add- In the Manage Add-ons window, select “All add-ons” CONVISION CC-8*** Cameras User Manual...
  • Page 27 Scroll down and find one of the ActiveX controls, and click the More Information link. In the More Information window, click Remove to clear the ActiveX control from IE. Repeat this for the remaining ActiveX components. CONVISION CC-8*** Cameras User Manual...
  • Page 28 Restore Factory Default Replaces factory default settings via the web UI. Network and/or user account settings can be saved if the corresponding check boxes are selected. Reboot Device CONVISION CC-8*** Cameras User Manual...
  • Page 29 Double click on folders to go up/down a directory level. 2.6 System – Record Setting When recording is done via event triggers, Record Setting will define how the recording is performed. Record Stream Profile will only display currently enabled streams. CONVISION CC-8*** Cameras User Manual...
  • Page 30 Select DHCP or Static IP for the camera. If using static, then enter the appropriate settings for your environment. Please confirm all network related settings with the network administrator prior to making any changes. 2.8 Network – Streaming CONVISION CC-8*** Cameras User Manual...
  • Page 31 If the IP camera uses DHCP, a DDNS service can provide a hostname for use with the IP camera. Registration with one of the DDNS service providers (ddns.nu, dyndns.org) is required for use of this feature. CONVISION CC-8*** Cameras User Manual...
  • Page 32 When TV Out Mode has been enabled, 2 video profiles will be enabled. Profile 2 will change to settings which will be used for the video out display (e.g. D1 resolution). Profile 1 settings will not be modified. CONVISION CC-8*** Cameras User Manual...
  • Page 33 Setting for specific ROI profiles can be found in the Video Quality Setting section. ROI profile 1 & 2 are preconfigured profiles which have some settings that are configurable (e.g. FPS). All profiles offer Constant Bit Rate (CBR) or Variable Bit Rate (VBR) mode. CONVISION CC-8*** Cameras User Manual...
  • Page 34 In the Region Size settings, the image has a mask covering area that will not be displayed; the lighter shaded area will be what is displayed for the ROI. To adjust the ROI, click & drag the window or click within the masked area to reposition. 2.11 Video/Audio – Audio Setting CONVISION CC-8*** Cameras User Manual...
  • Page 35 While noise reduction will smooth pixilation (usually in dark areas), too much may result in blurring. IR-Cut Filter: controls IR filter operation B/Win night mode: deselect if black & white not desired in night mode CONVISION CC-8*** Cameras User Manual...
  • Page 36 This applies only to a user-defined event. If 2 motion detection events have been configured (e.g. MD1 and MD2), then if MD1 is triggered, MD2 can still be triggered regardless of MD1’s Period Time setting. Be sure to click SAVE in the main Event Rule screen to save any changes. CONVISION CC-8*** Cameras User Manual...
  • Page 37 NFS and Samba are supported; if enabled then input relevant details. 2.15 Event Handle – Motion Detection To use motion detection, motion detection should be enabled and at least one motion detection area enabled. Checking the box for an Area (e.g. Area 1) enables it. CONVISION CC-8*** Cameras User Manual...
  • Page 38 Pelco P and D are supported as well as RS-485 and RS-422 communication modes. Please refer to the PTZ device’s required settings to configure the web UI PTZ settings. 2.17 System Log – View Log The System Log displays system and event details. CONVISION CC-8*** Cameras User Manual...
  • Page 39 Event Log contains information related to events triggered. 2.18 System Log – Remote Log Setting The System and/or Event log data can also be remotely logged. Check the box to enable and provide the corresponding log server address. CONVISION CC-8*** Cameras User Manual...
  • Page 40 Using VLC for example, select Media from the menu bar and Open Network Stream. Next specify IP address of the camera and stream profile. Click Play and video will begin streaming in the video player. WARNING: firewalls and other network security may prevent video streaming. CONVISION CC-8*** Cameras User Manual...
  • Page 41 Then a username/password must be supplied with the RTSP URL rtsp://USERNAME:PASSWORD@[IP ADDRESS]/rtpvideo[1-4].sdp 3.2 Image Snapshot in a Browser To view an image snapshot in a browser, the jpeg.cgi call will provide a VGA snapshot. http://<IP ADDRESS>/config/jpeg.cgi CONVISION CC-8*** Cameras User Manual...
  • Page 42 4 ADDING A CAMERA TO AN NVR The following gives some basic guidance for adding CONVISION MP cameras to an NVR system that supports RTSP streaming. Please refer to the NVR instructions for specific details on how to add and administer cameras for the NVR system.
  • Page 43 To assign a specific profile stream to the NVR, then append the appropriate profile number to the access name: rtsp://[IP ADDRESS]/[ACCESSNAME][PROFILE#].sdp example: rtsp://10.1.21.38/rtpvideo3.sdp 4.2 Administrator User & Password The administrator username is “root” and the default password is “pass”. CONVISION CC-8*** Cameras User Manual...
  • Page 44 5 FIREFOX While there is support for Firefox, the Live View interface will not have many of the controls available in IE. These controls are implemented using ActiveX which is only supported by IE. CONVISION CC-8*** Cameras User Manual...
