- Page 1 Manual CC-5501-E Date: August 2011 Convision Systems GmbH Manual CC 5501-E...
- Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- Page 3 Warning The camera requires periodic inspection. Contact an authorised technician to carry out the inspection. Stop using your camera when you find it malfunctioning. If the camera emits smoke or is unusually hot for a long period, a fire may be caused. Do not install the camera on a surface that can not support it.
-
Page 4: Table Of Contents
Contents NOTICE Important Safeguard Precautions Features Components and Accessories Overview Front View Top View Rear View Lens Using an Auto Iris Lens When using a CS mount Lens When using a C mount Lens Connecting to a Monitor Connecting to Power Camera Operation Menu Settings... -
Page 5: Notice
NOTICE Important Safeguard 1. Read Instructions Read all of the safety and operating instructions before using the product. 2. Retain Instructions Save these instructions for future reference. 3. Attachments / Accessories Do not use attachments or accessories unless recommended by the appliance manufacturer as they may cause hazards, damage product and void warranty. -
Page 6: Features
Features Ultra High Resolution resulting in a clear and sharp image even in By adopting a diagonal 6mm (1/3”) 410,000 low light. (NTSC) pixel, 470,000 (PAL) pixel Sony CCD the camera produces clear picture Privacy Function quality with a horizontal resolution of 600 The Privacy function conceals the areas TV lines for colour. -
Page 7: Components And Accessories
Components and Accessories 1. Ultra High Resolution Day & Night CCD Camera 2. Auto Iris Lens Connector Plug 3. L-Wrench 4. C-Mount Adapter 5. Instruction Manual Overview Front View 1. Lens protection cap Cover the lens when note in use. 2. -
Page 8: Top View
Top View 4. Mounting Bracket Use the screw holes provided when fixing the camera onto a mounting bracket. Use the clamp screw as shown in the picture. * The mounting bracket can be attached to either the bottom or the top of the camera. -
Page 9: Lens
9. Setting button Set Button: Used for the menu display. This button can be used to confirm settings after changing the value of the selected function or current conditions. Up & Down Buttons: Used for selecting items by moving the cursor up or down on the menu screen. -
Page 10: When Using A Cs Mount Lens
3. Remove the cover of the Auto Iris Lens connector plug and solder the lens cable to the connector pins of the plug. For a Video Drive Lens For a DC Drive Lens Pin 1: Red (Power) Pin 1: Damping – Pin 2: NC Pin 2: Damping + Pin 3: White (Video Signal) -
Page 11: When Using A C Mount Lens
When using a C mount Lens 1. Take off the lens protection cap and attach the C-mount adaptor. 2. Attach the C-Mount lens to the camera by screwing in clockwise. Note Use a lens threaded as shown in the following figure. If the dimensions of the thread are incorrect the camera could be damaged, or the lens may not get installed firmly enough. -
Page 12: Connecting To Power
Connecting to Power Since power specifications differ depending on the model, make sure to check your model name and specifications before connecting power. You can connect power as shown in the following figure. For AC / DC Power Check the standard power requirement before connecting to power. Dual Power Type AC90~230V-50Hz/60Hz 4.5W (AC 24V/DC 12V, AC 24V Class2) -
Page 13: Settings
Settings Settings can be made using the 5 buttons on the rear of the camera. 1. Press the SET button Settings can now be made. The SETUP menu is displayed on the monitor. 2. Select a menu item from the list available by using the UP and Down buttons. Functions are selected using up and down buttons The selected position is displayed in blue. -
Page 14: Exposure
DC/Video: Auto Iris Lens selection Note The brightness of the screen can be adjusted in DC mode. The brightness can be adjusted within the range of 0~255. The optimum level of brightness can be achieved using this adjustment. Manual: Manual Lens selection Exposure When the SETUP menu screen is displayed, select EXPOSURE by using up and down buttons so that the arrow indicates EXPOSURE. -
Page 15: White Balance
White Balance The screen colours can be adjusted using the WHITE BALANCE function. 1. Position the cursor to point to WHITE BAL on the SETUP menu by using the up and down buttons. 2. Select the mode you wish to adjust by pressing left and right buttons. You can select: ... -
Page 16: Blc (Back Light Compensation)
BLC (Back Light Compensation) When there is a strong backlight behind the object, clear images of the background as well as the object can still be obtained by using the BACKLIGHT function. 1. Position the cursor to point to 'BLC' on the SETUP menu by using the UP and DOWN buttons. -
Page 17: Day / Night
Day / Night Pictures can be displayed in either colour or black and white. 1. When the SETUP menu screen is displayed, select DAY/NIGHT using the up and down buttons. 2. Select the desired mode using the left and right buttons. Colour: The picture is displayed in colour. -
Page 18: Dpc (Dead Pixel Compensation)
DPC (dead pixel compensation) Users can compensation max. 64 point of dead pixel Special 1. When the SETUP menu screen is displayed, select SPECIAL using the up and down buttons. 2. Select the desired mode using the left and right buttons. - Cam Title: If a title is entered, the title appears on the monitor. -
Page 19: Motion
Motion This product has a feature that allows you to observe movements of objects in 4 different areas on the screen, and the green shape appears on the screen when movement is detected; hence a single individual can conduct supervision efficiently. The camera detects an object's movement by sensing disparity of outline and level of brightness and colour. -
Page 20: Language
Language Select the appropriate menu language. Return Select this to save the SPECIAL menu settings and return to the SETUP menu. Reset Resets the camera settings to the factory defaults. Exit Press the SET button in the EXIT menu to save the current settings and exit the SETUP menu. Manual CC 5501-E... -
Page 21: Troubleshooting
Troubleshooting If there are problems in operation, please refer to the items below. If the problem persists, please contact the agent you purchased this product from. Problems Troubleshooting Nothing appears on the screen. • Please check the power connection. •... -
Page 22: Specifications
Specifications ITEM NTSC Power Source AC24V / DC12V DC 12V AV24V / DC12V DC12V 250mA / 400mA 300mA 240mA / 400mA 300mA Total Pixels 811 (H) x 508 (V) 795 (H) x 596 (V) Effective Pixels 768 (H) x 494 (V) 752 (H) x 582 (V) Size 1/3 inch interline transfer CCD...
