- Page 1 Manual CC-5400 Date: January 2011 Convision Systems GmbH Manual CC 5400...
- Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- Page 3 Warning The camera requires periodic inspection. Contact an authorised technician to carry out the inspection. Stop using your camera when you find it malfunctioning. If the camera emits smoke or is unusually hot for a long period, a fire may be caused. Do not install the camera on a surface that can not support it.
-
Page 4: Table Of Contents
Contents NOTICE Important Safeguard Precautions Features Product & Accessories Parts Name & Function DIP Switch Setup Installation with Ceiling Mount Bracket Installation with Wall Mount Bracket Cabling Operation Check points before operation Preset and Pattern Function Pre-Check Starting OSD Menu Reserved Preset Preset Swing... -
Page 5: Notice
NOTICE Important Safeguard 1. Read Instructions Read all of the safety and operating instructions before using the product. 2. Retain Instructions Save these instructions for future reference. 3. Attachments / Accessories Do not use attachments or accessories unless recommended by the appliance manufacturer as they may cause hazards, damage product and void warranty. -
Page 6: Features
Features ■ Camera Specifications • CCD Sensor : 1/4" Interline Transfer CCD • Zoom Magnification : ×10 Optical Zoom, ×10 Digital Zoom (Max×100 Zoom) • Day & Night Function, Privacy Mask and WDR (WDR possible Models only) • Various Focus Mode: Auto-Focus / Manual Focus / Semi-Auto Focus. •... -
Page 7: Product & Accessories
■ Alarm I/O Functions • 3 alarm sensor Inputs are available. • To reject external electric noise and shock perfectly, alarm sensor Input is decoupled with photo coupler. • The signal range of sensor input is from DC 5.0 to 12.0 volts to adopt various pplications. •... -
Page 8: Parts Name & Function
Options Wall Mount Bracket Ceiling Mount Bracket Parts Name & Function ● Dome Cover: Do not detach protection vinyl from dome cover before finishing all installation process to protect dome cover from scratches or dust. ● DIP Switch: Adjusts camera ID and protocols. ●... -
Page 9: Dip Switch Setup
● LAN Port: Used for the Ethernet connection. (IP addressable models only) ● Audio Port: Used for the audio in/out connection. (IP addressable models only) ● Reset Switch: Used to initialize all the network configurations to the factory default. (IP addressable models only) Press button for more than 5 seconds to initialize the network system. - Page 10 Communication Protocol Setup - Select the appropriate Protocol with DIP switch combination. - If you want to control using DVR or P/T controller, their protocol must be identical to camera. Otherwise, you can not control the camera. - If you changed camera protocol by changing DIP S/W, the change will be effective after you reboot the camera.
-
Page 11: Installation With Ceiling Mount Bracket
Installation with Ceiling Mount Bracket 1) Remove the ceiling tile from the ceiling and 2) Pull the wire(s) and cable(s) for the system cut a hole whose diameter is 30~40mm on the as below. Wire the cable(s) to the ports. Insert ceiling tile to pass the wire(s) and cable(s) the mounting hooks into the holes on the through to the upside of the ceiling. -
Page 12: Installation With Wall Mount Bracket
Installation with Wall Mount Bracket 1) Make a hole whose diameter is 30~40mm 2) Wire the cable(s) to the ports. Insert the on the mounting surface to pass the wire(s) mounting hooks into the holes on the and cable(s) through the mounting surface. surface of the main body and turn the main Then prepare the wall mount bracket. -
Page 13: Cabling
Cabling Port Description Main Cable Port Pin Number (RJ45) Connector / Wire Color Signal BNC Connector Video + Video - RS-485 + Yellow RS-485 - Orange Power + White Power - I/O Cable Port Pin Number (RJ45) Wire Color Signal Blue IN COM + Yellow... - Page 14 Power Description Carefully check the voltage and current capacity of the rated power. The rated power is indicated in the back of main unit. Model Input Voltage Range Current Consumption Analog Model 0.8A 2.5A DC12V Model DC11V~18V IP Addressable Model 1.3A 3.0A AC24V Model...
-
Page 15: Operation
If you want to use Alarm Input, the types of sensor must be selected in OSD menu. The sensor types are Normal Open and Normal. If sensor type is not selected properly, the alarm can be activated reversely. Operation Check points before operation Before power is applied, please check the cables carefully. -
Page 16: Starting Osd Menu
Starting OSD Menu ● Function: Using the OSD menu, Preset, Pattern, Swing, Group and Alarm Input function can be configured for each application. ● Enter Menu: <Go Preset> [95] Reserved Preset ● Description: Some Preset numbers are reserved to special functions. ●... -
Page 17: Preset
Preset ● Function: Max. 127 positions can be stored as Preset position. The Preset number can be assigned from 1 to 128, but 95 is reserved for starting OSD menu. Camera characteristics (i.e. White Balance, Auto Exposure) can be set up independently for each preset. Label should be blank and "Camera Adjust"... -
Page 18: Pattern
Pattern ● Function: Pattern Function is that a camera memorizes the path (mostly curve path) by joystick of controller for assigned time and revives the path exactly as it memorized. 4 Patterns are available and Maximum 1200 communication commands can be stored in a pattern. ●... -
Page 19: Group
Group ● Function: The group function allows running sequence of Presets, Pattern and/or Swings. Max 8 group can be stored. Each group can have max 20 action entities which can be preset, pattern or swing. Preset speed can be set up and the repeat number of Pattern & Swing can be set up in Group setup. - Page 20 each preset location. During jog operation, Global WB/AE value should be applied. All Local WB/AE value do not change although Global WB/AE value changes. ● Semi Auto Focus - This mode exchanges focus mode automatically between Manual Focus mode and Auto Focus mode by operation.
-
Page 21: How To Use Osd Menu
How to Use OSD Menu General Rules of Key Operation for Menu ● The menu items surrounded with ( ) always has its sub menu. ● For all menu level, to go into sub menu, press NEAR key. ● To go to up-one-level menu, press FAR key. ●... -
Page 22: Camera Setup
Privacy Zone Mask Setup Select area in image to mask. ● Mask No [1~4] Select Mask number. If the selected mask has already data, camera moves as it was set. Otherwise, "UNDEFINED" will be displayed under "Mask NO". ● Display [ON/OFF] Sets if camera makes mask shows or not on images. - Page 23 ● Line Lock [ON/OFF] If Line lock sync is ON, video signal is synchronized with AC power. Video can be fluctuated after setting is changed. White Balance Setup ● Focus Mode [AUTO/MANUAL] In Manual mode, Red and Blue level can be set up manually ●...
-
Page 24: Motion Setup
Motion Setup Setup the general functions of Pan/Tilt motions. ● Motion Lock [ON/OFF] If Motion Lock is set to ON, it is impossible to set up and delete Preset, Swing, Pattern and Group. It is possible only to run those functions. To set up and delete those functions, enter into OSD menu. -
Page 25: Preset Setup
Alarm Input Setup Match the Alarm sensor input to one of Preset positions. If an external sensor is activated, camera will move to corresponding preset position when this item is predefined. ● Alarm x Type [Normal OPEN/Normal CLOSE] ● Alarm x Action [NOT USED/PRESET 1~128] Assign counteraction Preset position to each Alarm input Preset Setup ●... - Page 26 Edit Preset Scene (1) Using Joystick, move camera to desired position. (2) By pressing NEAR key, save current PTZ data. (3) Press FAR key to cancel. Edit Preset Label (1) Edits label to show on monitor when camera arrives at presets. In Edit Label menu, a reverse rectangular is cursor.
-
Page 27: Swing Setup
Swing Setup ● Swing Number [1~8] Selects Swing number to edit. If a selected Swing has not defined, "NOT USED" is displayed in 1st Position and 2nd Position ● 1st Position [PRESET 1~128] 2nd Position Set up the 2 position for Swing function. If a selected preset is not defined, "UNDEFINED"... -
Page 28: Group Setup
Edit Pattern (1) By using Joystick, move to start position with appropriate zoom. To start pattern recording, press NEAR key. To exit this menu, press FAR key. (2) Move camera with joystick of controller or run preset function to memorize the path (mostly curve path) in a selected pattern. -
Page 29: System Initialize
(4) Set up items such as Action, ###, Dwell and OPT. (5) After finishing setting up a Action, press Near key to one- upper-level menu (Step 2). Move cursor Up/Down to select Action number and repeat Step 2 ~ Step 4 to edit selected Group. - Page 30 Initial Configuration Table Manual CC 5400...
-
Page 31: Specifications
Specifications Model X 10 Video Signal System NTSC ¼“ Interline Transfer CCD Max. Pixels 811 (H)x508(V) 410 K 795 (H)x596 (V) 470K Effective Pixels 768 (H)x494 (V) 380K 752 (H)x582 (V) 440K Horizontal Res. 500 TV Line (Color), 570 TV Line (B/W) S/N Ratio 50 dB (AGC Off) Zoom... -
Page 32: Dimension
Dimension Main Body Ceiling Mount Type Wall Mount Type Manual CC 5400...
