- Page 1 Manual CC-5304 IR Date: January 2011 Convision Systems GmbH Manual CC 5304IR...
- Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- Page 3 Warning The camera requires periodic inspection. Contact an authorised technician to carry out the inspection. Stop using your camera when you find it malfunctioning. If the camera emits smoke or is unusually hot for a long period, a fire may be caused. Do not install the camera on a surface that can not support it.
-
Page 4: Table Of Contents
Contents NOTICE Important Safeguard Precautions Features Names and Functions of Parts Dimensions Installation Cable Connections Camera Operation Menu Settings Lens (selection) Shutter (condition and speed control) White Balance BACKLIGHT (Back Light Compensation) AGC (Auto Gain Control) DNR (Digital Noise Reduction) SENS UP (Low illuminance) Special EXIT... -
Page 5: Notice
NOTICE Important Safeguard 1. Read Instructions Read all of the safety and operating instructions before using the product. 2. Retain Instructions Save these instructions for future reference. 3. Attachments / Accessories Do not use attachments or accessories unless recommended by the appliance manufacturer as they may cause hazards, damage product and void warranty. -
Page 6: Features
Features Horizontal Resolution of 540 TV Lines Controlled by OSD Menu Clear image quality has been achieved by The camera functions are controlled by employing a SONY CCD with 410,000 selecting text displayed on the monitor (effective) pixels, which provides a screen. -
Page 7: Names And Functions Of Parts
Names and Functions of Parts 1. Lens: Vari-Focal DC Auto Iris Lens 2. OSD PCB ● SET button: Used for the menu display. This button can be used to confirm settings after changing the value of the selected function or current conditions. ●... -
Page 8: Dimensions
3. VBS-EXTRA for Connecting to LCD Please use the supplied wire when connecting to LCD. 4. Photo Sensor & IR LED (18pcs) IR LEDs are auto switching according to the control of photo sensor. 5. 3 Axis Bracket Please loosen screws and fix tilted and panned position. 6. -
Page 9: Installation
Installation Manual CC 5304IR... -
Page 10: Cable Connections
1. Dome Base Mounting - Open the dome cover by loosening 3 screws using special wrench provided. - Mount the base of camera to a sturdy surface using 4 screws (1.5 inch) and 4 premade holes on the base of the dome. 2. -
Page 11: Camera Operation
Camera Operation Menu Setup Menü Lens (selection) Manual Shutter (conditions and speed control) Manual White Balance Manual Backlight (Backlight Compensation) MIDDLE HIGH AGC (Auto Gain Control) MIDDLE HIGH DNR (Digital Noise Reduction) MIDDLE HIGH Sens-Up (Low Illuminance) Auto Special Camera Titel Day/Night SYNC Cam ID... -
Page 12: Lens (Selection)
2. Auswählen der einzelnen Punkte mit Hilfe der UP and DOWN Tasten. 3. When the LEFT or RIGHT button is pressed, available values and modes are displayed in order. Keep pressing the button until you get to the mode you wish to select. 4. -
Page 13: Shutter (Condition And Speed Control)
3. Press the SET button if you which to return to the previous menu. Shutter (condition and speed control) Auto or manual control can be selected. 1. When the SETUP menu is on the screen, position the cursor to point to SHUTTER by using the UP and DOWN buttons. -
Page 14: Backlight (Back Light Compensation)
o ATW(Auto Tracking White Balance): This mode can be used within the colour temperature range 1,800°K ~ 10,500°K (eg, fluorescent light, outdoor, sodium vapour lamp etc.) o AWC(Auto White Balance Control): Press the SET button while the camera is directed at a piece of white paper to obtain the optimum state under current illumination. -
Page 15: Agc (Auto Gain Control)
AGC (Auto Gain Control) 1. Position the cursor to point to 'AGC' on the SETUP menu by using the UP and DOWN buttons. 2. Select the value required by pressing the LEFT or RIGHT button. As the level of gain increases the screen gets brighter but the level of noise will also increase. -
Page 16: Sens Up (Low Illuminance)
OFF : There is no reduction in noise level. LOW : There is a small reduction in noise level with almost no ghost image. MIDDLE : The most effective mode. There is a sufficient reduction in noise levels without causing significant ghosting. HIGH : The level of noise is reduced greatly, however there is an increase in ghosting. -
Page 17: Special
Notiz • The maximum storage magnification in low light level movement situations can be adjusted by pressing the SET button in AUTO mode. (X2~X128) • As the magnification increase the screen gets brighter; however the after image also increasees. • If storage magnification is increased while SENS UP is operational, it may cause noise and spots may appear;... - Page 18 4) Up to 15 characters can be used for the camera ID. • Move the cursor to the letter required by using the UP and DOWN button. • Select an ID from A, B~Y, Z, a, b ~ y, z, 0,1~8,9 by using the UP, DOWN, LEFT and RIGHT buttons. •...
- Page 19 COLOR AUTO: This camera has an IR Cut Filter and automatically changes to the appropriate mode dependant on lighting levels. COLOR mode is selected during daylight and B/W mode at night time. Note • When the AGC is turned off, COLOR does not operate. •...
- Page 20 MOTION DETECTION: This product has a feature that allows you to observe movements of objects in 4 different areas on the screen, and the words 'MOTION DETECTED' appear on the screen when movement is detected; hence a single individual can conduct supervision efficiently. The camera detects an object's movement by sensing disparity of outline, and level of brightness and colour.
-
Page 21: Exit
SHARPNESS The outline of the video image becomes cleaner and more distinctive as the level of SHARPNESS increases. If the level goes up excessively, however, it may affect the video image and generate noise. • Please press the SETUP button. •... -
Page 22: Troubleshooting
Troubleshooting If there are problems with the camera operation, check the tables below. If the problem persists, please contact the agent who supplied the product. Problems Troubleshooting Nothing appears on the screen. • Check the power connection. • Check the video signal line connection. The video image is not clear •... -
Page 23: Specification
Specification NTSC Power Source AC24V/DC12V DC12V AC24V/DC12V DC12V 320mA(AC24V)/440mA(DC12V) 310mA 320mA(AC24V)/440mA(DC12V) 310mA Total Pixels 811(H) x 508(V) 795(H) x 596(V) Effective Pixels 768(H) x 494(V) 752(H) x 582(V) Size 1/3 inch interline transfer CCD Scanning System 2:1 Interlace Synchronization sync Frequency Horizontal: 15.734 KHz Vertical: 59.94 Hz Horizontal: 16.625 KHz...
