- Page 1 Manual CC-5308 Date: January 2011 Convision Systems GmbH Manual CC 5308...
- Page 2 The lightning flash with an arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
- Page 3 Warning The camera requires periodic inspection. Contact an authorised technician to carry out the inspection. Stop using your camera when you find it malfunctioning. If the camera emits smoke or is unusually hot for a long period, a fire may be caused. Do not install the camera on a surface that can not support it.
-
Page 4: Table Of Contents
Contents NOTICE Important Safeguard Precautions Features Components Names and Functions of Parts Dimensions Installation Cable Connections Camera Operation Menu Configuration Settings LENS (selection) Exposure WHITE BALANCE SSDR (Super Dynamic Range) BACKLIGHT DNR3 (Super Noise Reduction) Day / Night SPECIAL EXIT Troubleshooting Specifications Manual CC 5308... -
Page 5: Notice
NOTICE Important Safeguard 1. Read Instructions Read all of the safety and operating instructions before using the product. 2. Retain Instructions Save these instructions for future reference. 3. Attachments / Accessories Do not use attachments or accessories unless recommended by the appliance manufacturer as they may cause hazards, damage product and void warranty. -
Page 6: Features
Features Ultra High Resolution For images with high contrast between By adopting a diagonal 6mm (1/3”) 410,000 bright and dark spots from difficult lighting (NTSC) pixel, 470,000 (PAL) pixels SONY conditions such as backlighting, this CCD, the camera procedures clear picture camera selectively illuminates darker spots quality with a horizontal resolution of 600 while retaining the same light level for... -
Page 7: Components
Components 1. Color Dome Camera 2. Screws 3. Wrench 4. Wire for VBS-Extra 5. Instruction Guide Names and Functions of Parts 1. LENS: Vario-Focal DC Auto Iris Lens 2. OSD PCB Manual CC 5308... -
Page 8: Dimensions
●SET button: Used for the menu display. This button can be used to confirm settings after changing the value of the selected function or current conditions. ●UP & DOWN buttons: Used for selecting items by moving the cursor up or down on the menu screen. -
Page 9: Installation
Installation 1. Dome Base Mounting - Open the dome cover by loosening 3 screws using special wrench provided. - Mount the base of camera to a sturdy surface using 4 screws (1.5 inch) and 4 premade holes on the base of the dome. 2. -
Page 10: Cable Connections
Cable Connections Control via RS-485 Interface (Optional) The camera can be controlled by using external controllers like a Remote controller. (RS-485 Communication) • To control using a DVR or System Controller Connect the RS-485 cable (TRX+, TRX-) to the connection port of the 485 control board that is connected to the DVR or System Controller. -
Page 11: Settings
Settings Settings can be made using the 5 buttons located in the camera. 1. Press the Setup button - Main setup menu is displayed on the monitor screen. 2. Select a desired function using the Up and Down buttons. - Place the cursor over a desired item. Manual CC 5308... -
Page 12: Lens (Selection)
3. Set up a selected item by using the Left and Right buttons. 4. To finish the setting, select EXIT and press the Set button. Note appears at the mode selected, it means that there is a sub-menu which can be selected by pressing the SETUP button. -
Page 13: Exposure
Exposure 1. When the SETUP menu screen is displayed, select EXPOSURE by using the Up and Down buttons so that the arrow indicates EXPOSURE. 2. Select a desired mode using the Up and Down buttons. ● SHUTTER: You can select either auto or manual shutter. - A.FLK: Select this when you experience picture flicker, which can happen when there is a clash with the frequency of the installed lighting. -
Page 14: White Balance
● RETURN: Select this to save the changes in the EXPOSURE menu and return to the SETUP menu. Note • If you press the SET button in 'AUTO' mode, You can adjust brightness by increasing or decreasing the shutter speed. (X2~X512) •... -
Page 15: Ssdr (Super Dynamic Range)
SSDR (Super Dynamic Range) SSDR illuminates darker spots of an image while retaining the same light level for brighter spots to even out the overall brightness of images with high contrast between bright and dark spots. 1. When the SETUP menu screen is displayed, select 'SSDR' by using the Up and Down buttons so that the arrow indicates 'SSDR'. - Page 16 - MASKCOLOR/TONE: Change the color /brightness of the masking area. (Black, Red, Blue, Cyan, Magenta) - TOP/BOTTOM/LEFT/RIGHT: Adjust the area to be enhanced. • OFF: Not being used. 3. Select a desired mode using the Left and Right buttons and press the SET button. •...
-
Page 17: Dnr3 (Super Noise Reduction)
DNR3 (Super Noise Reduction) This function reduces the background noise in a low luminance environment. 1. When the SETUP menu screen is displayed, select ’DNR’ by using the Up and Down buttons so that the arrow indicates ’DNR’. 2. Select a desired mode using the Left and Right buttons. ●... -
Page 18: Special
● COLOR: The picture is always displayed in color. ● B/W: The picture is always displayed in black and white. ● AUTO: The mode is switched to Color in a normal environment, but switches to B/W mode when ambient illumination is low. To set up the switching time or speed for AUTO mode, press the SET button. - Page 19 ● Image Adj: 1) When the SETUP menu screen is displayed, select 'IMAGE ADJ.' by using the Up and Down buttons so that the arrow indicates 'IMAGE ADJ'. 2) Select a desired mode using the Up and Down buttons. • V-REV: You can flip the picture vertically on the screen. •...
- Page 20 ● CAMERA TITLE: If you enter a title, the title will appear on the monitor. 1) If the SPECIAL menu screen is displayed, use the Up and Down buttons so that the arrow indicates 'CAM TITLE'. 2) Set it to 'ON' by using the Left and Right buttons. 3) Press the SET button.
-
Page 21: Exit
- FILL→SET: Fills in a selected MD area. Fills in a selected MD area. The color of filling is sequentially selected as brown, orange, blue, cyan, yellowish green, yellow and red. - RETURN: Select this to save the MOTION DET menu settings and return to the SPECIAL menu. •... -
Page 22: Troubleshooting
Troubleshooting If there are problems in operation, please refer to the items below. If the problem persists, please contact the agent you purchased this product from. Problems Troubleshooting Nothing appears on the screen. • Please check the power connection. • Please check the video signal line connection. •... -
Page 23: Specifications
Specifications Item NTSC Power Consumption AC24V/DC12V DC12V AC24V/DC12V DC12V 300mA(AC24V / 400mA 300mA(AC24V / 400mA 450mA (DC12V) 450mA (DC12V) Effective Pixels 768(H) x 494(V) 752(H) x 582(V) Image Sensor SONY 1/3“ Super HAD High Sensitivity Color CCD Scanning System 2:1 Interlace Synchronization INT / LL sync...
